Packaging Methods
www.vishay.com
Vishay Dale
Revision: 11-Apr-16
1
Document Number: 34150
For technical questions, contact: magnetics@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
SMD Magnetics Packaging Methods
TAPE AND REEL in inches [millimeters] - Meets EIA RS-481 tape and reel packaging standard
MODEL
PACKAGE CODE
REEL
SIZE
CARRIER
TAPE
WIDTH
(W)
COMPONENT
PITCH
(P)
UNITS/
REEL
PACKAGE CODE
UNITS/
BULK
PREVIOUS
CODE
GLOBAL
CODE
LEAD (Pb)-
BEARING
GLOBAL
CODE
LEAD
(Pb)-FREE
PREVIOUS
CODE
GLOBAL
CODE
LEAD
(Pb)-
BEARING
GLOBAL
CODE
LEAD
(Pb)-FREE
IHLP-1212ABER - - ER 13 0.472 [12.0] 0.315 [8.0] 3000 - - - -
IHLP-1212ABEV - - ER 13 0.472 [12.0] 0.315 [8.0] 4000 - - - -
IHLP-1212AEER - - ER 13 0.472 [12.0] 0.315 [8.0] 3000 - - - -
IHLP-1212BZER - - ER 13 0.472 [12.0] 0.315 [8.0] 3000 - - - -
IHLP-1212BZEV - - ER 13 0.472 [12.0] 0.315 [8.0] 4000 - - - -
IHLP-1616AB - - ER 13 0.472 [12.0] 0.315 [8.0] 4000 - - EB 100
IHLP-1616BZ - - ER 13 0.472 [12.0] 0.315 [8.0] 4000 - - EB 100
IHLP-2020AB - - ER 13 0.472 [12.0] 0.315 [8.0] 4000 - - EB 100
IHLP-2020BZ - - ER 13 0.472 [12.0] 0.315 [8.0] 2000 - - EB 100
IHLP-2020CZ - - ER 13 0.472 [12.0] 0.315 [8.0] 2000 - - EB 100
IHLP-2525AH - - ER 13 0.630 [16.0] 0.315 [8.0] 2000 - - EB 100
IHLP-2525BD - - ER 13 0.630 [16.0] 0.315 [8.0] 2000 - - EB 100
IHLP-2525CZ - - ER 13 0.630 [16.0] 0.315 [8.0] 2000 - - EB 100
IHLP-2525EZ - - ER 13 0.630 [16.0] 0.472 [12.0] 500 - - EB 100
IHLP-3232CZ - - ER 13 0.630 [16.0] 0.472 [12.0] 1000 - - EB 100
IHLP-3232DZ - - ER 13 0.630 [16.0] 0.472 [12.0] 500 - - EB 100
IHLP-4040DZ - - ER 13 0.945 [24.0] 0.630 [16.0] 500 - - EB 100
IHLP-5050CE - - ER 13 0.945 [24.0] 0.630 [16.0] 500 - - EB 100
IHLP-5050EZ - - ER 13 0.945 [24.0] 0.630 [16.0] 250 - - EB 100
IHLP-5050FD - - ER 13 0.945 [24.0] 0.630 [16.0] 250 - - EB 100
IHLP-6767DZ - - ER 13 0.945 [24.0] 0.945 [24.0] 250 - - EB 100
IHLP-6767GZ - - ER 13 0.945 [24.0] 0.945 [24.0] 200 - - EB 100
IHLP-8787MZ - - ER 13 1.73 [44.0] 1.26 [32.0] 100 - - - -
IHCL-4040DZ - - ER 13 0.945 [24.0] 0.630 [16.0] 500 - - EB 100
IHLD-4032KB - - ER 13 0.945 [24.0] 0.630 [16.0] 250 - - EB 100
IHLD-3232HB - - ER 13 0.945 [24.0] 0.630 [16.0] 250 - - EB 100
IHLE-2525CD - - ER 13 0.630 [16.0] 0.315 [8.0] 2000 - - EB 100
IHLE-3232DD - - ER 13 0.630 [16.0] 0.472 [12.0] 500 - - EB 100
IHLE-4040DD - - ER 13 0.945 [24.0] 0.630 [16.0] 500 - - EB 100
IHLR-4040DZ - - ER 13 0.945 [24.0] 0.630 [16.0] 500 - - EB 100
IHLM-2525CZ - - ER 13 0.630 [16.0] 0.315 [8.0] 2000 - - EB 100
IHLW-4040CF - - ER 13 0.945 [24.0] 0.630 [16.0] 500 - - EB 100
IHLW-5050CE - - ER 13 0.945 [24.0] 0.630 [16.0] 500 - - EB 100
IFLP-4040DZ - - ER 13 0.945 [24.0] 0.630 [16.0] 500 - - EB 100
IFLR-2727EZ - - ER 13 0.630 [16.0] 0.630 [16.0] 1000 - - - -
IFLR-4027EZ - - ER 13 0.945 [24.0] 0.630 [16.0] 1000 - - - -
IFLR-4031GC - - ER 13 0.945 [24.0] 0.472 [12.0] 500 - - EB 100
IFLR-5151HZ - - ER 13 0.945 [24.0] 0.630 [16.0] 450 - - EB 100
User Direction of Feed
Carrier Dimensions
P
W
