The one-stop MEMS and

Sensors supplier

ST’s leadership continues with a strong commitment to Sustainable

Technology, delivering motion MEMS products with decreasing

environmental impact, generation after generation, providing improved

life quality by bringing environmental and social beneﬁts to end users.

SUSTAINABLE

TECHNOLOGY

• A unique sensor portfolio, from discrete to fully-integrated solutions,

to meet all design needs

• High-volume manufacturing capacity to provide cost-competitive

solutions, fast time-to-market and security of supply

• High-performance sensor fusion to improve the accuracy of multi-

axis sensor systems in order to enable new emerging and

highly-demanding applications, such as indoor navigation and

location-based services such as IoT, indoor navigation and

location-based services

• High-quality products, already tested in different application ﬁelds,

including mobile, portable, gaming, consumer, automotive and

health care segments

• Multiple sites dedicated to MEMS, with full in-house dual sourcing,

guaranteeing 100% security of supply

For your MEMS needs, ST provides a complete solution

ST has shipped more than 10 billion micro-electromechanical sensors and has one of the industry’s most

extensive MEMS portfolio including accelerometers, gyroscopes, digital compasses, inertial modules, MEMS

microphones, and environmental sensors including pressure, temperature and humidity.

COMPLETE SOLUTION

• Largesensorportfolio

• IntegratedHW+SWsolutions

• 100%securityofsupply

• Scalabilityofsolutions

• QualityisamustforST

• STisMEMSmarketleader

• STM32OpenDevelopment

Environmentsupport
