XP POWER JHM1012S12 直流/直流转换器 隔离式板载, 医用, DIP, 固定, 通孔安装, 10 W, 12 V, 833 mA
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
引脚图在P2Hot
导航目录
JHM1012S12数据手册
Page:
of 2 Go
若手册格式错乱，请下载阅览PDF原文件
DCDC
Specification
10 Watts
• International Medical Approvals
• 4000 VAC Reinforced Insulation
• Meets IEC606011, 3
rd
Edition
• 2 µA Patient Leakage Current
•
DIP24 Package
• EN55011 Level A With No External Components
• 3 Year Warranty
JHM10 Series
Input
Input Voltage Range • 5 V (4.5-9 VDC)
12 V (9-18 VDC)
24 V (18-36 VDC)
Input Current • See table
Inrush Current • 20 A max at 36 V
Input Filter • Pi network
Patient Leakage • 2 µA max
Current
Undervoltage Lockout • 5 V models, on at >4.4 V, off <4.2 V
12 V models, on at >8.8 V, off <8.3 V
24 V models, on at >17.5 V, off <17.0 V
Input Surge • 5 V models 15 V for 3 s
12 V models 25 V for 3 s
24 V models 50 V for 3 s
Output
Output Voltage • See table
Output Voltage Trim • ±10%
Minimum Load • No minimum load required
Initial Set Accuracy • ±1% max on V1, ±2% max on V2
Start Up Delay • 5 ms typical
Start Up Rise Time • 2 ms typical
Line Regulation • ±0.3% max
Load Regulation • ±2% max 0% to 10% load,
±1% max 10% to 100% load
Cross Regulation • ±4% max on dual with one output set to
50% load and the other varied from
10% to 100% load (D05 is 20% to 100%)
Transient Response • 4% max deviation, recovery to within 1%
in <500 µs for a 50% load change at
0.25 A/µs rate
Ripple & Noise • 1% pk-pk max at 20 MHz bandwidth
Overload Protection • 120% - 200%, trip and restart
Overvoltage Protection • 115% - 140%
Temperature • ±0.03/°C max
Coefficient
Short Circuit Protection • Trip and Restart (hiccup mode),
auto recovery
xppower.com
General
Efficiency • See tables
Isolation • 4000 VAC for 1 min. double/reinforced with
a working voltage of 250 VAC. Meets 2 x
MOPP per 3rd edition of IEC60601-1
5000 VAC for 10 ms in accordance with
IEC60664-1
Input to Output • 20 pF max
Capacitance
Switching Frequency • 80 kHz to 1.2 MHz variable
Power Density • 20.0 W/in
3
MTBF • >1 MHrs typical to MIL-STD-217F
at 25 °C, GB
Environmental
Operating Temperature • -40 °C to +80 °C, see derating curve
Case Temperature • +100 °C max
Storage Temperature • -40 °C to +100 °C
Operating Humidity • 5-90%, non-condensing
Cooling • Natural convection
EMC & Safety
Emissions • EN55011 & EN55022 level A conducted &
radiated with no external components
Immunity • IEC60601-1-2, EN61204-3
ESD Immunity • EN61000-4-2, level 2, Perf Criteria A
Radiated Immunity • EN61000-4-3, 10 V/m Perf Criteria A
EFT/Burst • EN61000-4-4, level 2 Perf Criteria A
Surge • EN61000-4-5, level 1 Perf Criteria A
Conducted Immunity • EN61000-4-6, 10 Vm, Perf Criteria A
Magnetic Field • EN61000-4-8, 3 A/m Perf Criteria A
Safety Approvals • ANSI/AMMI ES60601-1 3rd Edition
CSA-22.2 No.60601-1:2008
IEC60601-1 3
rd
Edition
