LC1D098C7 其他数据使用手册 - Schneider Electric（施耐德）
制造商:
Schneider Electric（施耐德）
分类:
工业继电器/通用
描述:
4 极交流控制接触器使用类别 AC1 辅助触点配置，一个常开，一个常闭 LC1D 接触器宽度为 45mm LC1D 系列闭合时间为 12-22ms，工作时间为 4-19ms 这些接触器切勿与 TeSys 过载继电器、互连装置或 GV2 断路器一起使用 ### 认可UL 和 CSA### Schneider Electric TeSys D 系列
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
LC1D098C7数据手册
Page:
of 4 Go
若手册格式错乱，请下载阅览PDF原文件
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
Mar 9, 2013
1
Product data sheet
Characteristics
LC1D098C7
TeSys D contactor - 4P(2 NO + 2 NC) - AC-1 -
<= 440 V 20 A - 32 V AC coil
