3
Mechanical durability
(millions)
15 Mcycles
Operating rate 3600 cyc/h at <= 60 °C
Complementary
Coil technology Without built-in suppressor module
Control circuit voltage limits 0.3...0.6 Uc at 60 °C drop-out 50/60 Hz
0.8...1.1 Uc at 60 °C operational 50 Hz
0.85...1.1 Uc at 60 °C operational 60 Hz
Inrush power in VA 70 VA at 20 °C (cos φ 0.75) 60 Hz
70 VA at 20 °C (cos φ 0.75) 50 Hz
Hold-in power consumption in VA 7.5 VA at 20 °C (cos φ 0.3) 60 Hz
7 VA at 20 °C (cos φ 0.3) 50 Hz
Heat dissipation 2...3 W at 50/60 Hz
Auxiliary contacts type Type mechanically linked (1 NO + 1 NC) conforming to IEC 60947-5-1
Type mirror contact (1 NC) conforming to IEC 60947-4-1
Signalling circuit frequency 25...400 Hz
Minimum switching current 5 mA for signalling circuit
Minimum switching voltage 17 V for signalling circuit
Non-overlap time 1.5 ms on de-energisation (between NC and NO contact)
1.5 ms on energisation (between NC and NO contact)
Insulation resistance > 10 MOhm for signalling circuit
Environment
IP degree of protection IP2x front face conforming to IEC 60529
Protective treatment TH conforming to IEC 60068-2-30
Pollution degree 3
Ambient air temperature for operation -5...60 °C
Ambient air temperature for storage -60...80 °C
Permissible ambient air temperature around the de-
vice
-40...70 °C at Uc
Operating altitude 3000 m without derating in temperature
Fire resistance 850 °C conforming to IEC 60695-2-1
Flame retardance V1 conforming to UL 94
Mechanical robustness Vibrations contactor open 2 Gn, 5...300 Hz
Vibrations contactor closed 4 Gn, 5...300 Hz
Shocks contactor open 10 Gn for 11 ms
Shocks contactor closed 15 Gn for 11 ms
Height 77 mm
Width 45 mm
Depth 86 mm
Product weight 0.325 kg
