3
Mechanical durability 4 Mcycles
Operating rate 3600 cyc/h at <= 60 °C
Complementary
Coil technology Without built-in suppressor module
Control circuit voltage limits 0.85...1.1 Uc at 55 °C operational 60 Hz
0.8...1.1 Uc at 55 °C operational 50 Hz
0.3...0.6 Uc at 55 °C drop-out 50/60 Hz
Inrush power in VA 245 VA at 20 °C (cos ϕ 0.75) 50 Hz
245 VA at 20 °C (cos ϕ 0.75) 60 Hz
Hold-in power consumption in VA 26 VA at 20 °C (cos ϕ 0.3) 50 Hz
26 VA at 20 °C (cos ϕ 0.3) 60 Hz
Heat dissipation 6...10 W at 50/60 Hz
Auxiliary contacts type Type mirror contact (1 NC) conforming to IEC 60947-4-1
Type mechanically linked (1 NO + 1 NC) conforming to IEC 60947-5-1
Signalling circuit frequency 25...400 Hz
Minimum switching current 5 mA for signalling circuit
Minimum switching voltage 17 V for signalling circuit
Non-overlap time 1.5 ms on energisation (between NC and NO contact)
1.5 ms on de-energisation (between NC and NO contact)
Insulation resistance > 10 MOhm for signalling circuit
Environment
IP degree of protection IP2x front face conforming to IEC 60529
Protective treatment TH conforming to IEC 60068-2-30
Pollution degree 3
Ambient air temperature for operation -5...60 °C
Ambient air temperature for storage -60...80 °C
Permissible ambient air temperature around the de-
vice
-40...70 °C at Uc
Operating altitude 3000 m without derating in temperature
Fire resistance 850 °C conforming to IEC 60695-2-1
Flame retardance V1 conforming to UL 94
Mechanical robustness Shocks contactor closed 10 Gn for 11 ms
Shocks contactor open 8 Gn for 11 ms
Vibrations contactor closed 3 Gn, 5...300 Hz
Vibrations contactor open 2 Gn, 5...300 Hz
Height 127 mm
Width 85 mm
Depth 130 mm
Product weight 1.61 kg
Contractual warranty
Period 18 months
