2
Main
Range of product TeSys F
Product or component
type
Contactor
Device short name LC1F
Contactor application Resistive load
Utilisation category AC-1
Poles description 2P
Power pole contact
composition
2 NO
[Ue] rated operational
voltage
<= 460 V DC
<= 1000 V AC 50/60 Hz
[Ie] rated operational
current
500 A (<= 40 °C) at <= 440 V AC AC-1
Control circuit type AC 40...400 Hz
Control circuit voltage 110 V AC 40...400 Hz
[Uimp] rated impulse
withstand voltage
8 kV
Overvoltage category III
[Ith] conventional free
air thermal current
500 A at <= 40 °C
Irms rated making ca-
pacity
4000 A AC conforming to IEC 60947-4-1
Rated breaking capac-
ity
3200 kA conforming to IEC 60947-4-1
[Icw] rated short-time
withstand current
1000 A <= 40 °C 10 min
1200 A <= 40 °C 3 min
1700 A <= 40 °C 1 min
2400 A <= 40 °C 30 s
3600 A <= 40 °C 10 s
Associated fuse rating 500 A gG at <= 440 V
400 A aM at <= 440 V
Average impedance 0.26 mOhm at 50 Hz - Ith 500 A
[Ui] rated insulation
voltage
1500 V conforming to VDE 0110 group C
1000 V conforming to IEC 60947-4-1
Power dissipation per
pole
65 W AC-1
Mounting support Plate
Standards EN 60947-1
EN 60947-4-1
IEC 60947-1
IEC 60947-4-1
JEM 1038
Product certifications BV
CCC
CSA
DNV
GL
RINA
RMRoS
UL
LROS
