The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
Mar 9, 2013
1
Product data sheet
Characteristics
LC1F500L7
TeSys F contactor - 3P (3 NO) - AC-3 - <= 440
V 500 A - coil 208 V AC
Main
Range of product TeSys F
Product or component
type
Contactor
Device short name LC1F
Contactor application Motor control
Resistive load
Utilisation category AC-1
AC-3
Poles description 3P
Power pole contact
composition
3 NO
[Ue] rated operational
voltage
<= 460 V DC
<= 1000 V AC 50/60 Hz
[Ie] rated operational
current
500 A (<= 55 °C) at <= 440 V AC AC-3
700 A (<= 40 °C) at <= 440 V AC AC-1
Motor power kW 147 kW at 220...230 V AC 50/60 Hz
335 kW at 1000 V AC 50/60 Hz
335 kW at 660…690 V AC 50/60 Hz
355 kW at 500 V AC 50/60 Hz
295 kW at 440 V AC 50/60 Hz
280 kW at 415 V AC 50/60 Hz
250 kW at 380...400 V AC 50/60 Hz
Control circuit type AC 40...400 Hz
Control circuit voltage 208 V AC 40...400 Hz
[Uimp] rated impulse
withstand voltage
8 kV
Overvoltage category III
[Ith] conventional free
air thermal current
700 A at <= 40 °C
Irms rated making ca-
pacity
5000 A AC conforming to IEC 60947-4-1
Rated breaking capac-
ity
4000 kA conforming to IEC 60947-4-1
[Icw] rated short-time
withstand current
1200 A <= 40 °C 10 min
1500 A <= 40 °C 3 min
2400 A <= 40 °C 1 min
3200 A <= 40 °C 30 s
4200 A <= 40 °C 10 s
Associated fuse rating 800 A gG at <= 440 V
500 A aM at <= 440 V
Average impedance 0.18 mOhm at 50 Hz - Ith 700 A
[Ui] rated insulation
voltage
1500 V conforming to VDE 0110 group C
1000 V conforming to IEC 60947-4-1
Power dissipation per
pole
45 W AC-3
88 W AC-1
Mounting support Plate
Standards EN 60947-1
EN 60947-4-1
IEC 60947-1
IEC 60947-4-1
JEM 1038
