Main
Commercial Status Commercialised
Range of product TeSys D
Product or component
type
Reversing contactor
Device short name LC2D
Contactor application Motor control
Resistive load
Utilisation category AC-1
AC-3
Device presentation Preassembled with reversing power busbar
Poles description 3P
Pole contact
composition
3 NO
[Ue] rated operational
voltage
<= 300 V DC for power circuit
<= 690 V AC 25...400 Hz for power circuit
[Ie] rated operational
current
25 A (<= 140 °F (60 °C)) at <= 440 V AC AC-1 for power
circuit
9 A (<= 140 °F (60 °C)) at <= 440 V AC AC-3 for power
circuit
Motor power kW 5.5 kW at 660...690 V AC 50/60 Hz
5.5 kW at 500 V AC 50/60 Hz
4 kW at 415...440 V AC 50/60 Hz
4 kW at 380...400 V AC 50/60 Hz
2.2 kW at 220...230 V AC 50/60 Hz
Motor power hp 7.5 hp at 575/600 V AC 50/60 Hz for 3 phases motors
5 hp at 460/480 V AC 50/60 Hz for 3 phases motors
2 hp at 230/240 V AC 50/60 Hz for 3 phases motors
2 hp at 200/208 V AC 50/60 Hz for 3 phases motors
1 hp at 230/240 V AC 50/60 Hz for 1 phase motors
0.5 hp at 115 V AC 50/60 Hz for 1 phase motors
Control circuit type AC 50/60 Hz
Control circuit voltage 24 V AC 50/60 Hz
Auxiliary contact
composition
1 NO + 1 NC
[Uimp] rated impulse
withstand voltage
6 kV conforming to IEC 60947
Overvoltage category III
[Ith] conventional free
air thermal current
25 A at <= 140 °F (60 °C) for power circuit
10 A at <= 140 °F (60 °C) for signalling circuit
Irms rated making
capacity
250 A DC for signalling circuit conforming to IEC
60947-5-1
140 A AC for signalling circuit conforming to IEC
60947-5-1
250 A at 440 V for power circuit conforming to IEC 60947
Rated breaking
capacity
250 A at 440 V for power circuit conforming to IEC 60947
[Icw] rated short-time
withstand current
140 A 100 ms signalling circuit
120 A 500 ms signalling circuit
100 A 1 s signalling circuit
210 A <= 104 °F (40 °C) 1 s power circuit
105 A <= 104 °F (40 °C) 10 s power circuit
61 A <= 104 °F (40 °C) 1 min power circuit
30 A <= 104 °F (40 °C) 10 min power circuit
Associated fuse rating 10 A gG for signalling circuit conforming to IEC
60947-5-1
20 A gG at <= 690 V coordination type 2 for power circuit
25 A gG at <= 690 V coordination type 1 for power circuit
Average impedance 2.5 mOhm at 50 Hz - Ith 25 A for power circuit
