Lattice Semiconductor Home Page: http://www.latticesemi.com Applications & Literature Hotline: 1-800-LATTICE
Copyright 2014 Lattice Semiconductor Corporation. Lattice Semiconductor, L(stylized) Lattice Semiconductor Corporation, and Lattice (design) either registered trademarks or trademarks o fattice Semiconductor Corporation in the United States
and/or other countr i e s . O t h e r p ro duc t n a m es u s e d i n this publications ar e f o r i d e n t i f i c ation purpos e s o nly a nd m ay b e t he tra d em ark s o f th e ir r espe ctiv e c om p ani e s.
Data Sheet Specifications
This PCN has no impact on any data sheet specifications.
Qualification Data
Qualification data pertinent to this PCN can be found here.
Characterization Data
A device characterization report is available here.
Frequently Asked Questions (FAQ)
Lattice recommends that customers refer to the FAQ document available here to find answers to commonly asked
questions regarding this PCN.
Conversion Timeline
Conversion timing for this PCN is 90 days from the date of this Notice. No action is required (meaning no changes to
OPNs, your internal Bills of Material, backlog or orders) unless you plan to do further evaluation. Should samples be
required to complete evaluation of this PCN, such sample requests must be received no later than May 14, 2014 (30
days after the date of this Notice). Samples for this PCN will use the “CU3” suffix appended to the standard OPNs as
shown in the example below:
Example:
Standard OPN: LCMXO2-1200ZE-1TG144C
Amkor Philippines Cu-wire Custom OPN: LCMXO2-1200ZE-1TG144CCU3
Conversion Timing Summary
Sample Request Cut-off Date: May 14, 2014
PCN Expiration Date: July 14, 2014
Backlog
Lattice recommends that customers complete their evaluation before the PCN Expiration Date (July 14, 2014). Lattice
will begin shipping devices manufactured at Amkor Philippines with Cu-wire as early as July 14, 2014. Any customer
who does not want to receive devices manufactured at Amkor Philippines w Cu-wire beyond the PCN Expiration Date
must initiate a change order request to convert their backlog to the “CA2” suffix appended to the standard OPN as
shown in the example next page:
