VRLA BATTERIES AUGUST 2005
VALVE-REGULATED LEAD ACID BATTERIES: INDIVIDUAL DATA SHEET
This information is generally descriptive only and is not intended to make or imply any representation, guarantee or warranty with respect to any cells and batteries. Cell and battery designs/specifications are subject to
modification without notice. Contact Panasonic for the latest information.
For main and standby power supplies.
Expected trickle life: 3-5 years at 25°C, Approx. 5 years at 20°C.
LC-RA1212P
Specifications
Characteristics
Dimensions (mm)
Discharge characteristics 77°F (25°C)
(Note)
Duration of discharge vs. Discharge current
(Note)
Photo/Label for reference only.
(Note) The above characteristics data are average values obtained
within three charge/discharge. Cycles not the minimum values.
Terminal type: Faston 187 or Faston 250
(13.5±0.75)
(98 )
+
-
1.5
0.5
(10 )
1.0
+
0.394
3.858
0.012
(0.3)
3.701
(94 )
+
-
1.5
0.5
0.236 (6)
0.534
±0.3
5.945
151
+
-
1.5
0.5
0.039
+
0.059
0.020
+
-
0.059
0.020
+
-
0.059
0.020
+
-
14.4
13.8
13.2
12.6
12.0
11.4
10.8
10.2
9.6
9.0
8.4
7.8
0 1 2 4 6 8 10 20 40 60 2 4 6 8 10 20 40
(Minute) (Hour)
Duration of discharge
Terminal voltage (V)
6A
3A
1.2A
0.6A
24A
12A
300 500 1 3 5 10 30 50 100
30
20
15
10
5
4
3
2
1.5
1
50
40
30
20
10
5
3
(Minute) (Hour)
Duration of discharge
(mA)
(A)
Discharge current
104˚F (40˚C)
77˚F (25˚C)
32˚F (0˚C)
5˚F (-15˚C)
Battery case resin: Standard (UL94HB) Color is black.
* The total height with #250 teminal is 101.5mm.
Nominal Voltage
Rated Capacity (20 hour rate)
12V
12Ah
5.945 inches (151.0 mm
)
3.860 inches (98.0 mm)
3.702 inches (94.0 mm)
3.937 inches (100.0 mm
)
8.36 lbs. (3.8 kg)
LC-RA1212P
LC-RA1212P1
Dimensions
Standard Terminals
and Resin
Length
Width
Height
Total Height*
Approx. mass
UL94HB Faston 250
UL94HB Faston 187
Capacity
(note)
77˚F (25˚C)
Self discharge
77˚F (25˚C)
5.8A
102%
100%
85%
65%
20 hour rate (600mA)
10 hour rate (1130mA)
5 hour rate (2080mA)
1 hour rate (8100mA)
1.5 hour rate discharge
Cut-off voltage 10.5 V
12Ah
11.3Ah
10.4Ah
8.1Ah
Internal Resistance
Fully charged battery
77˚F (25˚C)
Residual capacity
after standing 3 months
Residual capacity
after standing 6 months
Residual capacity
after standing 12 months
91%
82%
64%
Approx. 30mΩ
4.8 A or smaller
1.8 A or smaller
Initial current
Control voltage
Initial current
Control voltage
14.5V to 14.9V
(per 12V cell 25˚C
)
13.6V to 13.8V
(per 12V cell 25˚C
)
104˚F (40˚C)
77˚F (25˚C)
32˚F (0˚C)
5˚F (-15˚C)
Temperature
dependency
of capacity
(20 hour rate)
Charge
Method
(Constant
Voltage)
Cycle use
(Repeating
use)
Trickle use
