Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
Supply Voltage 16V
Control Pin Voltage (Pins 4, 7, 9, 12,
14) V
CC
Operating Temperature Range 0˚C to +70˚C
Storage Temperature Range −65˚C to +150˚C
Power Dissipation 1W
Lead Temp. (Soldering, 10 seconds) 260˚C
Note 1: “Absolute Maximum Ratings” indicate limits beyond which damage
to the device may occur. Operating Ratings indicate conditions for which the
device is functional, but do not guarantee specific performance limits.
Electrical Characteristics
V
CC
=12V, T
A
=25˚C (unless otherwise stated)
Parameter Conditions Min Typ Max Units
Supply Voltage Range Pin 11 9 16 V
Supply Current 35 45 mA
Zener Regulated Output Pin 17
Voltage 5.4 V
Current 5mA
Maximum Output Voltage Pins 8, 13; f=1 kHz
V
CC
=9V, Maximum Gain 0.8 Vrms
V
CC
=12V 0.8 1.0 Vrms
Maximum Input Voltage Pins 2, 19; f=1 kHz, V
CC
2V 1.3 1.6 Vrms
Gain=−10 dB
Input Resistance Pins 2, 19; f=1 kHz 20 30 kΩ
Output Resistance Pins 8, 13; f=1 kHz 20 Ω
Maximum Gain V(Pin 12)=V(Pin 17); f=1 kHz −2 0 2 dB
Volume Control Range f=1 kHz 70 75 dB
Gain Tracking f=1 kHz
Channel 1–Channel 2 0 dB through −40 dB 1 3 dB
−40 dB through −60 dB 2 dB
Balance Control Range Pins 8, 13; f=1 kHz 1 dB
−26 −20 dB
Bass Control Range f=40 Hz, C
b
=0.39 µF
(Note 3) V(Pin 14)=V(Pin 17) 12 15 18 dB
V(Pin 14)=0V −12 −15 −18 dB
Treble Control Range f= 16 kHz, C
t
,=0.01 µF
(Note 3) V(Pin 4)=V(Pin 17) 12 15 18 dB
V(Pin 4)=0V −12 −15 −18 dB
Total Harmonic Distortion f=1 kHz, V
IN
=0.3 Vrms
Gain=0 dB 0.06 0.3 %
Gain=−30 dB 0.03 %
Channel Separation f=1 kHz, Maximum Gain 60 75 dB
Signal/Noise Ratio Unweighted 100 Hz–20 kHz 80 dB
Maximum Gain, 0 dB=0.3 Vrms
CCIR/ARM (Note 4)
Gain=0 dB, V
IN
=0.3 Vrms 75 79 dB
Gain=−20 dB, V
IN
=1.0 Vrms 72 dB
Output Noise Voltage at CCIR/ARM (Note 4) 10 16 µV
Minimum Gain
Supply Ripple Rejection 200 mVrms, 1 kHz Ripple 35 50 dB
Control Input Currents Pins 4, 7, 9, 12, 14 (V=0V) −0.6 −2.5 µA
Frequency Response −1 dB (Flat Response 250 kHz
20 Hz–16 kHz)
LM1036
www.national.com 2
