IST-A0081
2.0
CreationDate Proto Rev Released
12/5/2016 20.00 0
NI Quantity
Reference
Value Rating Voltage Tolerance Type PCB_Footprint ManufacturerPN Manufacturer
Eval Board Name
Revision
1
R14
10 1W ±5% WW RES650-CW001|RES650-CW001-VERT CW00110R00JE12 Vishay
1
R15
10M 1/4W ±1% ThickFilm R1206 CR1206-4W-1005F Venkel
1
R16
4.7K 1/16W ±5% ThickFilm R0402|R0402L CRS0402-16W-472JT Venkel
1
R17
137K 1/16W ±1% ThickFilm R0402 CR0402-16W-1373F Venkel
1
R19
2.49K 1/16W ±1% ThickFilm R0402 CR0402-16W-2491F Venkel
1
R20
40.2K 1/16W ±1% ThickFilm R0402 CR0402-16W-4022F Venkel
1
R21
30.1K 1/16W ±1% ThickFilm R0402 CR0402-16W-3012FT Venkel
1
R22
0.5 1/4W ±1% ThickFilm R1206 RL1206FR-070R5L Yageo
1
R23
23.2K 1/16W ±1% ThickFilm R0402 CR0402-16W-2322FT Venkel
4
R3 R4 R7 R8
1K 1/16W ±1% ThickFilm R0402|R0402L CR0402-16W-1001F Venkel
1
R5
0.001 1.5W ±1% ThickFilm R2010 CSNL2010FT1L00 Stackpole Electronics Inc.
1
R6
0 2A ThickFilm R0805 CR0805-10W-000 Venkel
3
R9 R10 R24
10K 1/16W ±5% ThickFilm R0402 CR0402-16W-103J Venkel
1
RL1
8-1393239-5 16A 5V SPDT RLY-RT314F05 RT314F05 TE CONNECTIVITY
1
RT1
RING TERMINAL HDW 7113K23 McMaster-Carr
2
S1 S2
Socket Socket Custom Custom
1
S3
Socket Socket Custom Custom
1
SC1
PUSH BUTTON CAP Switch Cap BTN-K02-20 C&K COMPONENTS
1
T1
RLTI-1072 XFMR-RLTI-1072 RLTI-1072 RENCO ELECTRONICS
1
U1
UCC28700DBV SOT6N2.8P0.95 UCC28700DBV TI
1
U2
LM3671MF-3.3 600mA 3.3V Buck SOT5N2.8P0.95 LM3671MF-3.3/NOPB TI
1
W10
White 14 AWG Wire 2 Wire Wire 2 General Specification
1
W7
Green 14 AWG Wire 3 Wire Wire 3 General Specification
1
W8
Green 14 AWG Wire 4 Wire Wire 4 General Specification
1
W9
Black 14 AWG Wire 1 Wire Wire 1 General Specification
1
WA1
FLAT WASHER M2 HDW 91116A240 McMaster-Carr
Not Installed Components
NI Quantity
Reference
Value Rating Voltage Tolerance Type PCB_Footprint ManufacturerPN Manufacturer
NI 1
C14
33nF 16V ±10% X5R C0603 C0603X5R160-333KNE Venkel
NI 1
C15
150nF 16V ±5% X7R C0603 C0603X7R160-154JNE Venkel
NI 2
H1 H2
HDR_1x8 Header CONN1X8-1.27 GRPB081VWVN-RC Sullins Connector Solutions
NI 1
H3
HDR_1X4 Header CONN1X4-1.27 GRPB041VWVN-RC Sullins Connector Solutions
NI 2
MH1 MH2
AC RCPT AC_RCPT AC_RCPT 601-1-00188 SILU HASO
NI 3
MH19 MH20
MH21
Slotted Screw Slotted Screw 91800A032 McMaster-Carr
