Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
ESD Tolerance (Note 2) 2.5 kV
Supply Voltage (V
+
–V
−
) 36V
Differential Input Voltage (Note 11)
±
10V
Output Short Circuit to Ground
(Note 3) Continuous
Storage Temperature Range −65˚C to +150˚C
Maximum Junction Temperature
(Note 4) 150˚C
Operating Ratings (Note 1)
Supply Voltage 5.5V ≤ V
S
≤ 36V
Junction Temperature Range
LM7171AI, LM7171BI −40˚C ≤ T
J
≤ +85˚C
Thermal Resistance (θ
JA
)
N Package, 8-Pin Molded DIP 108˚C/W
M Package, 8-Pin Surface Mount 172˚C/W
M Package, 16-Pin Surface Mount 95˚C/W
±
15V DC Electrical Characteristics
Unless otherwise specified, all limits guaranteed for T
J
=
25˚C, V
+
=
+15V, V
−
=
−15V, V
CM
=
0V, and R
L
=
1kΩ.Boldface
limits apply at the temperature extremes
Symbol Parameter Conditions Typ
(Note 5)
LM7171AI LM7171BI Units
Limit Limit
(Note 6) (Note 6)
V
OS
Input Offset Voltage 0.2 1 3 mV
47max
TC V
OS
Input Offset Voltage 35 µV/˚C
Average Drift
I
B
Input Bias Current 2.7 10 10 µA
12 12 max
I
OS
Input Offset Current 0.1 4 4 µA
66max
R
IN
Input Resistance Common Mode 40 MΩ
Differential Mode 3.3
R
O
Open Loop Output 15 Ω
Resistance
CMRR Common Mode V
CM
=
±
10V 105 85 75 dB
Rejection Ratio 80 70 min
PSRR Power Supply V
S
=
±
15V to
±
5V 90 85 75 dB
Rejection Ratio 80 70 min
V
CM
Input Common-Mode CMRR
>
60 dB
±
13.35 V
Voltage Range
A
V
Large Signal Voltage R
L
=
1kΩ 85 80 75 dB
Gain (Note 7) 75 70 min
R
L
=
100Ω 81 75 70 dB
70 66 min
V
O
Output Swing R
L
=
1kΩ 13.3 13 13 V
12.7 12.7 min
−13.2 −13 −13 V
−12.7 −12.7 max
R
L
=
100Ω 11.8 10.5 10.5 V
9.5 9.5 min
−10.5 −9.5 −9.5 V
−9 −9 max
Output Current Sourcing, R
L
=
100Ω 118 105 105 mA
(Open Loop) 95 95 min
(Note 8) Sinking, R
L
=
100Ω 105 95 95 mA
90 90 max
www.national.com3
