LM6511

www.ti.com

SNOS695C –JUNE 1999–REVISED MARCH 2013

LM6511 180 ns 3V Comparator

Check for Samples: LM6511

FEATURES DESCRIPTION

The LM6511 voltage comparator is ideal for analog-

• (Typical Unless Otherwise Noted)

digital interface circuitry when only a +3V or +3.3V

• Operates at +2.7V, +3V, +3.3V, +5V

supply is available. The open-collector output permits

• Low Power Consumption <9.45 mW @ V

signal compatibility with a wide variety of digital

2.7V (max)

families: +5V CMOS, +3V CMOS, TTL and so on.

Supply voltage may range from 2.7V to 36V between

• Fast Response Time of 180 ns

supply voltage leads. The LM6511 operates with little

power consumption (P

diss

< 9.45 mW at V

= +2.7V

APPLICATIONS

and V

−

= 0V).

• Portable Equipment

This voltage comparator offers many features that are

• Cellular Phones

available in traditional sub-microsecond comparators:

• Digital Level Shifting output sync strobe, inputs and output may be isolated

from system ground, and wire-ORing. Also, the

LM6511 uses the industry-standard, single

comparator pinout configuration.

Connection Diagram

Figure 1. 8-Pin SOIC

See Package Number D

These devices have limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam

during storage or handling to prevent electrostatic damage to the MOS gates.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

2All trademarks are the property of their respective owners.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW
