AC Electrical Characteristics (Continued)
Note 1: Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for which the device is
intended to be functional, but do not guarantee specific performance limits. For guaranteed specifications and test conditions, see the Electrical Characteristics. The
guaranteed specifications apply only for the test conditions listed.
Note 2: Applies to both single-supply and split-supply operation. Continous short circuit operation at elevated ambient temperature can result in exceeding the
maximum allowed junction temperature of 150˚C. Output currents in excess of
±
30 mA over long term may adversely affect reliability.
Note 3: The maximumpowerdissipation is a function of T
J(Max)
, θ
JA
, and T
A
. The maximum allowable power dissipation at any ambienttemperatureisP
D
=(T
J(Max)
−T
A
)/θ
JA
.
Note 4: Human body model, 1.5 kΩ in series with 100 pF.
Note 5: Typical values represent the most likely parametric norm.
Note 6: All limits are guaranteed by testing or statistical analysis.
Note 7: V
+
= 15V, V
CM
= 7.5V and R
L
connected to 7.5V. For Sourcing tests, 7.5V ≤ V
O
≤ 11.5V. For Sinking tests, 2.5V ≤ V
O
≤ 7.5V.
Note 8: V
+
= 15V. Connected as Voltage Follower with 10V step input. Number specified is the slower of the positive and negative slew rates.
Note 9: For operating at elevated temperatures the device must be derated based on the thermal resistance θ
JA
with P
D
=(T
J
–T
A
)/θ
JA
.
Note 10: Do not connect output to V
+
, when V
+
is greater than 13V or reliability witll be adversely affected.
Note 11: All numbers apply for packages soldered directly into a PC board.
Note 12: For guaranteed Military Temperature Range parameters see RETSMC6061X.
LMC6061
www.national.com 4
