191:
9.95k
10k,
0.1%
10k, 0.1%
10k,
0.1%
50:
A2
A1
+
-
V
OUT
= 100V
D
V
CM
- 1/2V
D
10:
Gain
Trim
V
CM
+ 1/2V
D
CMRR
Trim
LMC6462, LMC6464
www.ti.com
SNOS725D –MAY 1999–REVISED MARCH 2013
LMC6462 Dual/LMC6464 Quad Micropower, Rail-to-Rail Input and Output CMOS
Operational Amplifier
Check for Samples: LMC6462, LMC6464
1
FEATURES
DESCRIPTION
The LMC6462/4 is a micropower version of the
2
• (Typical Unless Otherwise Noted)
popular LMC6482/4, combining Rail-to-Rail Input and
• Ultra Low Supply Current 20 μA/Amplifier
Output Range with very low power consumption.
• Ensured Characteristics at 3V and 5V
The LMC6462/4 provides an input common-mode
• Rail-to-Rail Input Common-Mode Voltage
voltage range that exceeds both rails. The rail-to-rail
Range
output swing of the amplifier, ensured for loads down
to 25 kΩ, assures maximum dynamic signal range.
• Rail-to-Rail Output Swing
This rail-to-rail performance of the amplifier,
– (within 10 mV of rail, V
S
= 5V and R
L
= 25
combined with its high voltage gain makes it unique
kΩ)
among rail-to-rail amplifiers. The LMC6462/4 is an
• Low Input Current 150 fA
excellent upgrade for circuits using limited common-
mode range amplifiers.
• Low Input Offset Voltage 0.25 mV
The LMC6462/4, with ensured specifications at 3V
APPLICATIONS
and 5V, is especially well-suited for low voltage
applications. A quiescent power consumption of 60
• Battery Operated Circuits
μW per amplifier (at V
S
= 3V) can extend the useful
• Transducer Interface Circuits
life of battery operated systems. The amplifier's 150
• Portable Communication Devices
fA input current, low offset voltage of 0.25 mV, and
85 dB CMRR maintain accuracy in battery-powered
• Medical Applications
systems.
• Battery Monitoring
Figure 1. 8-Pin PDIP/SOIC – Top View Figure 2. 14-Pin PDIP/SOIC – Top View
(See Package Number P or D) (See Package Number NFF0014A or D)
Figure 3. Low-Power Two-Op-Amp Instrumentation Amplifier
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2All trademarks are the property of their respective owners.
PRODUCTION DATA information is current as of publication date.
Copyright © 1999–2013, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
