Texas Instruments, Inc. PCN#20150122001
PCN Number:
20150122001
PCN Date:
02/12/2015
Title:
Qualification of ASESH for Alternate Assembly/Test and new material set for select
MSOP Devices
Customer Contact:
PCN Manager
Dept:
Quality Services
Proposed 1
st
Ship Date:
05/12/2015
Estimated Sample Availability:
04/12/2015
Change Type:
Assembly Site
Assembly Process
Assembly Materials
Design
Electrical Specification
Mechanical Specification
Test Site
Packing/Shipping/Labeling
Test Process
Wafer Bump Site
Wafer Bump Material
Wafer Bump Process
Wafer Fab Site
Wafer Fab Materials
Wafer Fab Process
Part number change
PCN Details
Description of Change:
Texas Instruments is pleased to announce the qualification of ASESH as an alternate assembly
and test site for selected MSOP devices listed below. The material set comparing the existing and
new site is shown below.
TIEM
ASESH
Mount Compound
8075531
SID#EY1000063
Mold Compound
4209002
SID#EN2000515
Lead Finish
Matte Sn
NiPdAu
Test coverage, insertions, conditions will remain consistent with current testing and verified with
test MQ.
Upon expiry of this PCN TI will combine lead free solutions in a single standard part number, for
example; LDC4029MM/NOPB – can ship with both Matte Sn and NiPdAu/Ag.
Example:
– Customer order for 7500units of LDC4029MM/NOPB with 2500 units SPQ (Standard
Pack Quantity per Reel).
– TI can satisfy the above order in one of the following ways.
I. 3 Reels of NiPdAu finish.
II. 3 Reels of Matte Sn finish
III. 2 Reels of Matte Sn and 1 reel of NiPdAu finish.
IV. 2 Reels of NiPdAu and 1 reel of Matte Sn finish.
Reason for Change:
Continuity of Supply
Anticipated impact on Fit, Form, Function, Quality or Reliability (positive / negative):
None
Changes to product identification resulting from this PCN:
Assembly Site
TIEM-AT
Assembly Site Origin (22L)
ASO: CU6
ASESH
Assembly Site Origin (22L)
ASO: ASH
Sample product shipping label (not actual product label)
