Advance Product Change Notification 201506013A
Issue Date: 08-Feb-2016
Dear Product Change Notices Newark,
Here’s your personalized quality information concerning products
Newark purchased from NXP.
For detailed information we invite you to view this notification online
Management Summary
Dual sourcing of the LPC175X/6X products in the LQFP100, LQFP80 and TFBGA100 packages.
Add Powerchip as a new FAB. Add SPIL as an additional assembly site for the LQFP100 and LQFP80
packages.
Change Category
[ ] Wafer Fab process [X] Assembly Process [X] Product Marking [X] Design
[ ] Wafer Fab
materia
l
s
l
s
[ ] Ele
c
trical spec./T
e
s
t co
v
era
g
e
[ ]
Mechan
i
c
a
l Specificati
o
n
[X] Wafer F
a
b locati
o
n
[X] Assembly Location
[ ] Test Locat
i
on
[ ] Packing/Shippi
n
g/Labe
l
ing
Dual sourcing of the LPC175X/6X products in the LQFP100, LQFP80, TFBGA100
packages
Details of this Planned Change
Dual sourcing of the LPC175X/6X products in the LQFP100, LQFP80 and TFBGA100 packages.
- No change in data sheet
- No change in ordering part number / 12NC
- Final test location remains unchanged at NXP Assembly and Test Kaohsiung (ATKH)
The silicon wafers are currently produced in SSMC. This qualification will enable producing the silicon wafers at the
Powerchip FAB (PTCF12).
The die revision will be changed from Rev 6 to Rev 11 which includes design changes.
The die pad has been optimized to allow for Cu wire bonding.
ATKH will be qualified for the LQFP100, LQFP80 and TFBGA100 packages with the following changes:
