1. General description
The LPC2141/42/44/46/48 microcontrollers are based on a 16-bit/32-bit ARM7TDMI-S
CPU with real-time emulation and embedded trace support, that combine microcontrollers
with embedded high-speed flash memory ranging from 32 kB to 512 kB. A 128-bit wide
memory interface and a unique accelerator architecture enable 32-bit code execution at
the maximum clock rate. For critical code size applications, the alternative 16-bit Thumb
mode reduces code by more than 30 % with minimal performance penalty.
Due to their tiny size and low power consumption, LPC2141/42/44/46/48 are ideal for
applications where miniaturization is a key requirement, such as access control and
point-of-sale. Serial communications interfaces ranging from a USB2.0 Full-speed device,
multiple UARTs, SPI, SSP to I
2
C-bus and on-chip SRAM of 8 kB up to 40 kB, make these
devices very well suited for communication gateways and protocol converters, soft
modems, voice recognition and low end imaging, providing both large buffer size and high
processing power. Various 32-bit timers, single or dual 10-bit ADCs, 10-bit DAC, PWM
channels and 45 fast GPIO lines with up to nine edge or level sensitive external interrupt
pins make these microcontrollers suitable for industrial control and medical systems.
2. Features
2.1 Key features
n 16-bit/32-bit ARM7TDMI-S microcontroller in a tiny LQFP64 package
n 8 kB to 40 kB of on-chip static RAM and 32 kB to 512 kB of on-chip flash memory;
128-bit wide interface/accelerator enables high-speed 60 MHz operation
n In-System Programming/In-Application Programming (ISP/IAP) via on-chip boot
loader software, single flash sector or full chip erase in 400 ms and programming of
256 B in 1 ms
n EmbeddedICE RT and Embedded Trace interfaces offer real-time debugging with the
on-chip RealMonitor software and high-speed tracing of instruction execution
n USB 2.0 Full-speed compliant device controller with 2 kB of endpoint RAM
In addition, the LPC2146/48 provides 8 kB of on-chip RAM accessible to USB by DMA
n One or two (LPC2141/42 vs, LPC2144/46/48) 10-bit ADCs provide a total of 6/14
analog inputs, with conversion times as low as 2.44 µs per channel
n Single 10-bit DAC provides variable analog output (LPC2142/44/46/48 only)
n Two 32-bit timers/external event counters (with four capture and four compare
channels each), PWM unit (six outputs) and watchdog
LPC2141/42/44/46/48
Single-chip 16-bit/32-bit microcontrollers; up to 512 kB flash
with ISP/IAP, USB 2.0 full-speed device, 10-bit ADC and DAC
Rev. 03 — 19 October 2007 Product data sheet
