SpecNo.JELF243A-0103N-01 P1/8
MURATA MFG.CO., LTD
Reference Only
CHIP COIL (CHIP INDUCTORS) LQH2HPN□□□MGRL REFERENCE SPECIFICATION
1.Scope
This reference specification applies to LQH2HPN_GR Series, Chip coil (Chip Inductors).
2.Part Numbering
(ex) LQ H 2H P N 1R0 M G R L
Product ID
Structure
Dimension
Applications Category Inductance Tolerance Dimension
Other Packaging
(L×W)
and
(T)
L:Φ180Taping
Characteristics
3.Rating
Operating Temperature Range
(Ambient temperature; Self-temperature rise is not included) -40 to +105°C (except LQH2HPN101MGR)
(Product temperature; Self- temperature rise is included) -40 to +125°C (except LQH2HPN101MGR)
(Ambient temperature; Self-temperature rise is not included) -40 to +85°C (only LQH2HPN101MGR)
(Product temperature; Self- temperature rise is included) -40 to +105°C (only LQH2HPN101MGR)
Storage Temperature Range. -40 to +105°C (except LQH2HPN101MGR)
-40 to +85°C (only LQH2HPN101MGR)
Customer
Part Number
MURATA
Part Number
Inductance
DC
Resistance
(Ω)
Self
Resonant
Frequency
(MHz min)
Rated Current (mA)
∗1 Based on
Inductance
change
∗2 Based on
Temperature rise
(μH)
Tolerance
(%)
∗3 Ambient
temperature
(85 )℃
∗4 Ambient
temperature
(105 )℃
LQH2HPNR47MGRL 0.47
M:±20
0.045±20% 120 2900 2520 1470
LQH2HPNR68MGRL 0.68 0.055±20% 110 2430 2330 1350
LQH2HPN1R0MGRL 1.0 0.068±20% 100 2130 2100 1200
LQH2HPN1R5MGRL 1.5 0.087±20% 90 1700 1850 1110
LQH2HPN2R2MGRL 2.2 0.134±20% 80 1550 1470 850
LQH2HPN3R3MGRL 3.3 0.225±20% 70 1230 1100 660
LQH2HPN4R7MGRL 4.7 0.300±20% 50 1090 1000 570
LQH2HPN6R8MGRL 6.8 0.395±20% 40 830 860 490
LQH2HPN100MGRL 10 0.560±20% 30 700 710 430
LQH2HPN150MGRL 15 0.925±20% 20 570 560 310
LQH2HPN220MGRL 22 1.360±20% 15 460 430 250
LQH2HPN101MGRL 100 5.900±20% 5 210 150 -
∗1: When applied Rated current to the Products , Inductance will be within ±30% of initial inductance value range.
∗2:
Keep the temperature(ambient temperature plus self-generation of heat) under 125 . ℃ (except LQH2HPN101MGR)
Keep the temperature(ambient temperature plus self-generation of heat) under 105 . ℃ (only LQH2HPN101MGR)
∗3: When applied rated current to the Products, temperature rise caused by self-generated heat shall be limited to 40℃
max. (except LQH2HPN101MGR)
When applied rated current to the Products, temperature rise caused by self-generated heat shall be limited to 20℃
max. (only LQH2HPN101MGR)
∗4:When applied rated current to the Products,temperature rise caused by self-generated heat shall be limited to 20 ℃
max.
4. Testing Conditions
《Unless otherwise specified》 《In case of doubt》
Temperature : Ordinary Temperature (15 to 35°C) Temperature : 20 ± 2°C
Humidity : Ordinary Humidity (25 to 85 % (RH)) Humidity : 60 to 70 % (RH)
Atmospheric Pressure : 86 to 106 kPa
