LSA4L-2B
( Home : Products : Switches » MICRO SWITCH™ Limit Switches » MICRO
SWITCH™ Heavy-Duty Limit Switches » HDLS )
Series HDLS Non Plug-in: Side Rotary; 2NC 2NO DPDT Snap
Action; 0.75 in - 14NPT conduit
A
ctual product appearance
may vary.
click here to download Hi-Res image
Overview Specs Documentation Application Notes
Product Specifications
Availability Global
Operating Force (OF) 0,45 N m [4 in lb] max.
Pretravel (PT) 15° max.
Overtravel (OT) 60° min.
Differential Travel (DT) 7° max.
Product Type MICRO SWITCH™ Heavy-Duty Limit Switches
Actuator Side Rotary
Lever Type 1.5 in to 3.5 in Adjustable Length Lever with back mounted Steel Rollers (.75 in dia x .25 in
wide)
Circuitry 2NC 2NO DPDT Snap Action, Double-Break
Ampere Rating 10 A (Thermal)
Supply Voltage 600 Vac and 250 Vdc max.
Housing Material Zinc Die-Cast
Termination Type 0.75 in - 14NPT Conduit
Housing Type HDLS Non Plug-in
Series Name HDLS
Sealing NEMA 1, 3, 4, 4X, 6, 6P, 12, 13
UL File # E37138
Operating Temperature -12 °C to 121 °C [10 °F to 250 °F]
Comment Lever Included
Agency Approvals and
Standards
UL, CE, CSA, CCC. EN60947-1, EN60947-5-1
UNSPSC Code 302119
UNSPSC Commodity 302119 Switches and controls and relays
