M25P32 32Mb 3V NOR Serial Flash
Embedded Memory
Features
• SPI bus-compatible serial interface
• 32Mb Flash memory
• 75 MHz clock frequency (maximum)
• 2.7V to 3.6V single supply voltage
• V
PP
= 9V for FAST PROGRAM/ERASE mode (option-
al)
• Page program (up to 256 bytes) in 0.64ms (TYP)
• Erase capability
– Sector erase: 512Kb in 0.6s (TYP)
– Bulk erase: 23 s (TYP); 17s (TYP) with V
PP
= 9V
• Write protection
– Hardware write protection: protected area size
defined by nonvolatile bits BP0, BP1, BP2
• Deep power-down: 1µA (TYP)
• Electronic signature
– JEDEC-standard 2-byte signature (2016h)
– Unique ID code (UID) and 16 bytes of common
Flash interface (CFI) data
– RES command, one-byte signature (15h) for
backward-compatibility
• More than 100,000 write cycles per sector
• More than 20 years of data retention
• Automotive-grade parts available
• Packages (RoHS-compliant)
– SO8W (MW) 208 mils
– SO16 (MF) 300 mils
– VFQFPN8 (MP) MLP8 6mm x 5mm
– VFDFPN8 (MP) MLP8 8mm x 6mm
M25P32 Serial Flash Embedded Memory
Features
PDF: 09005aef84566541
m25p32.pdf - Rev. O 3/13 EN
1
Micron Technology, Inc. reserves the right to change products or specifications without notice.
© 2013 Micron Technology, Inc. All rights reserved.
Products and specifications discussed herein are subject to change by Micron without notice.
