November 2008 Rev 11 1/54
1
M25P32
32-Mbit, low voltage, serial Flash memory
with 75 MHz SPI bus interface
Features
32 Mbit of Flash memory
2.7 V to 3.6 V single supply voltage
SPI bus compatible serial interface
75 MHz clock rate (maximum)
V
PP
= 9 V for Fast Program/Erase mode
(optional)
Page Program (up to 256 bytes)
– in 0.64 ms (typical)
Sector Erase (512 Kbit) in 0.6 s (typical)
Bulk Erase:
– in 23 s (typical)
– in 17 s (typical with V
PP
= 9 V)
Deep Power-down mode 1 μA (typical)
Electronic Signatures
– JEDEC standard two-byte signature
(2016h)
– Unique ID code (UID) +16 bytes of CFI
data
– RES instruction, one-byte, signature (15h),
for backward compatibility
Hardware Write Protection of the memory area
selected using the BP0, BP1 and BP2 bits
More than 100 000 Erase/Program cycles per
sector
More than 20 year data retention
Packages
– RoHS compliant
Automotive certified parts available
VDFPN8 (ME)
8 × 6 mm (MLP8)
VFQFPN8 (MP)
6 × 5 mm
SO16 (MF)
SO8W (MW)
208 mils
300 mils width
www.Numonyx.com
