December 2007 Rev 13 1/55
1
M25P16
16 Mbit, serial Flash memory, 75 MHz SPI bus interface
Features
■ 16 Mbit of Flash memory
■ Page Program (up to 256 bytes) in 0.64 ms
(typical)
■ Sector Erase (512 Kbit) in 0.6 s (typical)
■ Bulk Erase (16 Mbit) in 13 s (typical)
■ 2.7 V to 3.6 V single supply voltage
■ SPI bus compatible serial interface
■ 75 MHz Clock rate (maximum)
■ Deep Power-down mode 1 µA (typical)
■ Electronic signatures
– JEDEC standard two-byte signature
(2015h)
– Unique ID code (UID) with 16 bytes read-
only, available upon customer request
– RES instruction, one-byte, signature (14h),
for backward compatibility
■ More than 100,000 Erase/Program cycles per
sector
■ Hardware Write Protection: protected area size
defined by three non-volatile bits (BP0, BP1
and BP2)
■ More than 20 year data retention
■ Packages
– ECOPACK® (RoHS compliant)
VDFPN8 (ME)
8 x 6 mm (MLP8)
SO16 (MF)
300 mils width
VFQFPN8 (MP)
6 × 5 mm (MLP8)
SO8N (MN)
150 mils width
SO8W (MW)
208 mils width
www.numonyx.com
