March 2010 Rev 12 1/55
1
M25P64
64 Mbit, low voltage, Serial Flash memory
with 75 MHz SPI bus interface
Features
64 Mbit of Flash memory
2.7 V to 3.6 V single supply voltage
SPI bus compatible serial interface
75 MHz clock rate (maximum)
Page Program (up to 256 Bytes)
– in 1.4 ms (typical)
– in 0.35 ms (typical with V
PP
= 9 V)
Sector Erase (512 Kbit)
Bulk Erase (64 Mbit)
Electronic Signatures
– JEDEC standard two-Byte signature
(2017h)
– RES instruction, one-Byte, signature (16h),
for backward compatibility
– Unique ID code (UID) with 16 bytes
readonly: available upon customer request
Hardware Write Protection: protected area size
defined by three non-volatile bits (BP0, BP1
and BP2)
More than 100 000 Erase/Program cycles per
sector
More than 20-year data retention
Packages
– RoHS compliant
Automotive certified parts available
VDFPN8 (ME)
8 × 6 mm (MLP8)
SO16 (MF)
300 mils width
www.numonyx.com
