Micron M25P80 Serial Flash Embedded
Memory
8Mb, 3V
Features
SPI bus-compatible serial interface
8Mb Flash memory
75 MHz clock frequency (maximum)
2.7V to 3.6V single supply voltage
Page program (up to 256 bytes) in 0.64ms (TYP)
Erase capability
Sector erase: 512Kb in 0.6 s (TYP)
Bulk erase: 8Mb in 8 s (TYP)
Write protection
Hardware write protection: protected area size
defined by nonvolatile bits BP0, BP1, BP2
Deep power-down: 1µA (TYP)
Electronic signature
JEDEC-standard 2-byte signature (2014h)
Unique ID code (UID) and 16 bytes of common
Flash interface (CFI) data
RES command, one-byte signature (13h) for
backward compatibility
More than 100,000 write cycles per sector
More than 20 years data retention
Automotive-grade parts available
Packages (RoHS-compliant)
SO8N (MN) 150 mils
SO8W (MW) 208 mils
VFDFPN8 (MP) MLP8 6mm x 5mm
UFDFPN8 (MC) MLP8 4mm x 3mm
Micron M25P80 Serial Flash Embedded Memory
Features
PDF: 09005aef84566560
m25p80.pdf - Rev. H 4/15 EN
1
Micron Technology, Inc. reserves the right to change products or specifications without notice.
© 2011 Micron Technology, Inc. All rights reserved.
Products and specifications discussed herein are subject to change by Micron without notice.
