1 Publication Order Number:
MAC228A/D
MAC228A Series
Sensitive Gate Triacs
Silicon Bidirectional Thyristors
Designed primarily for industrial and consumer applications for
full−wave control of AC loads such as appliance controls, heater
controls, motor controls, and other power switching applications.
Features
• Sensitive Gate Triggering in 3 Modes for AC Triggering on
Sinking Current Sources
• Four Mode Triggering for Drive Circuits that Source Current
• All Diffused and Glass−Passivated Junctions for Parameter
Uniformity and Stability
• Small, Rugged, Thermowatt Construction for Low Thermal
Resistance and High Heat Dissipation
• Center Gate Geometry for Uniform Current Spreading
• These Devices are Pb−Free and are RoHS Compliant*
TRIACS
8 AMPERES RMS
200 − 800 VOLTS
TO−220
CASE 221A
STYLE 4
MT1
G
MT2
3
4
1
2
MARKING DIAGRAM
MAC228AxxG
AYWW
xx = 4, 6, 8, or 10
A = Assembly Location (Optional)*
Y = Year
WW = Work Week
G = Pb−Free Package
See detailed ordering and shipping information in the package
dimensions section on page 4 of this data sheet.
ORDERING INFORMATION
* The Assembly Location code (A) is optional. In
cases where the Assembly Location is stamped
on the package the assembly code may be blank.
Littelfuse.com
Specifications subject to change without notice. © 2016 Littelfuse, Inc.
September 19, 2016 − Rev. 8
