Page 3 of 4
Intermittent
Operational
Life Test
(IOL)
MAC15A10G
77
136093
TA:25°C, TJ:125°C
(ΔTJ=100°C),
TON/OFF: 2 minutes,
15,000cycles
no failure at
15,000cycles
read point
MCR25NG
77
136630
MAC16CNG
77
136630
T2800DG
77
140422
MAC15A10G
77
140541
Resistance
to Solder
Heat (RSH)
MAC15A10G
10
136093
260°C, 10 seconds
no failure
after RSH
MCR25NG
10
136630
MAC16CNG
10
136630
Solderability
MAC15A10G
10
136093
245°C, 5 seconds
Meet
standard
requirement
MCR25NG
10
136630
MAC16CNG
10
136630
MAC16CNG
10
136630
Note: Reliability performance of products using wafers from new wafer site is better than existing
ones on leakage drifting result.
6.0 Electrical Characteristic Summary:
1. Turn-on time of new site wafers is typically longer 2.6µS than existing wafers and Turn-off time of
new site wafers is typically longer 18.21µS than existing wafers, these results are caused by the
new wafer chip size are larger than existing ones.
2. ITSM performance of new site wafers is typically higher 20A than existing wafers.
7.0 Changed Part Identification:
NA
8.0 Recommendations & Conclusions:
Based on above qualification test results, Littelfuse conclude that new wafer manufacture site transfer
activities are qualified and certified for Littelfuse WUXI TO-220AB non-isolated On Portfolio Thyristor
Products
Littelfuse released new wafer manufacture site to production for Littelfuse WUXI TO-220AB non-
isolated On Portfolio Thyristor Products
9.0 Approvals:
Lei Wu Peter Liu
Thyristor Product Engineer Sr. Product Engineer Manager
Littelfuse, Inc. Littelfuse, Inc.
