General Description
The MAX14578 evaluation kit (EV kit) provides a proven
design to evaluate the MAX14578 USB battery charger
detector in a 12-bump wafer-level package (WLP). The
IC features charger detection compliant to USB Battery
Charging Revision 1.1, dedicated charger detection,
Apple charger detection, China YD/T1591-compliant
charger detection, and USB pass-through communica-
tion. The EV kit has various power options to separate the
charging current from the system current. The EV kit is
self-powered through USB, but needs external power to
demonstrate charging. The EV kit features the MAX8903A
1-cell lithium-ion (Li+) DC-DC USB charger for interfacing
with the MAX14578 in an application setting.
The EV kit uses Windows XP
M
-, Windows Vista
M
-, and
Windows
M
7-compatible software to provide a simple
graphical user interface (GUI) to simplify evaluation. The
EV kit GUI enables testing of the IC’s features. The EV kit
PCBs come with a MAX14578EEWC+ installed.
Features
S Windows XP-, Windows Vista-, and Windows
7-Compatible Software
S GUI Simplifies Learning the IC’s Operation
S Includes MAX8903A USB Charger for Application
Testing
S Can be USB Powered or Externally Powered for
Greater Charging Current
S Proven PCB Layout
S Fully Assembled and Tested
DESIGNATION QTY DESCRIPTION
C1, C4, C6,
C7, C11, C12,
C100,
C102–C109
15
0.1FF Q10%, 25V X5R ceramic
capacitors (0603)
Murata GRM188R61E104K
C2, C5, C10 3
4.7FF Q10%, 25V X5R ceramic
capacitors (0805)
Murata GRM21BR61E475K
C8, C9 2
10uF Q10%, 10V X7R ceramic
capacitors (0805)
Murata GRM21BR71A106K
C13 1
2.2FF Q10%, 6.3V X5R ceramic
capacitor (0603)
Murata GRM185R60J225K
C14, C116 0
Not installed, ceramic capacitors
(0603)
C101 1
4.7FF Q10%, 6.3V X5R ceramic
capacitor (0603)
Murata GRM188R60J475K
C110, C111 2
10pF Q5%, 50V C0G ceramic
capacitors (0603)
Murata GRM1885C1H100J
DESIGNATION QTY DESCRIPTION
C112, C114 2
10FF Q10%, 6.3V X5R ceramic
capacitors (0603)
Murata GRM188R60J106M
C113, C115 2
1FF Q10%, 16V X7R ceramic
capacitors (0603)
Murata GRM188R71C105K
C117, C118 2
22pF Q5%, 50V C0G ceramic
capacitors (0603)
Murata GRM1885C1H220J
C119 1
3300pF Q10%, 50V X7R ceramic
capacitor (0603)
Murata GRM188R71H332K
CE1, CE2, CEN,
INT
4 White multipurpose test points
D1–D4 4
Red LEDs (0603)
Panasonic LNJ208R8ARA
D100 1
Green LED (0603)
Panasonic LNJ314G8TRA
DM, DP 0
Not installed, miniature test
points
MAX14578 Evaluation Kit
Evaluates: MAX14578
_________________________________________________________________ Maxim Integrated Products 1
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
Component List
19-5824; Rev 0; 4/11
Ordering Information appears at end of data sheet.
Windows, Windows XP, and Windows Vista are registered
trademarks of Microsoft Corp.
