General Description
The MAX3678 evaluation kit (EV kit) is a fully assembled
and tested demonstration board that simplifies evalua-
tion of the MAX3678 low-jitter frequency synthesizer
with intelligent dynamic switching (IDS). The EV kit
includes slide switches to allow easy selection of differ-
ent modes of operation. Clock I/Os have SMA connec-
tors and are AC-coupled to simplify connection to test
equipment. The EV kit is powered by a +3.3V supply
and uses LEDs for signal status indicators.
Features
♦ Fully Assembled and Tested
♦ Slide Switches for Mode Control
♦ SMA Connectors and AC-Coupled Clock I/Os
♦ Powered by +3.3V Supply
♦ LED Signal Status Indicators
Evaluates: MAX3678
MAX3678 Evaluation Kit
________________________________________________________________
Maxim Integrated Products
1
19-4273; Rev 0; 9/08
Component List
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
Ordering Information
DESIGNATION QTY DESCRIPTION
C1, C6, C7
C11–C13, C16,
C18–C22,
C24–C27, C29,
C30, C32–C39,
C41, C42,
C46–C50,
C62, C63
35
0.1μF ±10% ceramic capacitors
(0402)
C2 1
33μF ±5% tantalum capacitor
(B case)
C3 1 2.2μF ±10% ceramic capacitor (0805)
C4 1 0.1μF ±10% ceramic capacitor (0603)
C5 1
0.01μF ±10% ceramic capacitor
(0603)
C28 1
0.22μF ±10% ceramic capacitor
(0402)
D1, D3, D5,
D6, D8
5
Green SMD LEDs (1206)
Panasonic LNJ311G8PRA
D2, D4, D7 3
Red SMD LEDs (1206)
Panasonic LNJ211R8ARA
J1, J2,
J5–J12, J14,
J15, J19, J20,
J22–J29,
J44, J45
24
SMA connectors, edge-mount,
tab center
Johnson 142-0701-851
J4, J13 2
Test points
Keystone 5000
L13 1
4.7μH ±20% inductor
Taiyo Yuden CBC3225T4R7M
DESIGNATION QTY DESCRIPTION
R1–R5, R15,
R16, R17,
R37–R46
18 143 ±1% resistors (0402)
R6–R11 6 49.9 ±1% resistors (0402)
R12, R13, R14,
R18–R22
8 332 ±1% resistors (0603)
R23, R24, R25 3 10k ±1% resistors (0603)
S1 1
Switch, momentary, SPST-NO
Panasonic EVQQ2S02W
S2–S5 4
Switches, slide, SPDT
Copal Electronics CUS-12TB
S6, S7, S8 3
Switches, slide, SP4T
Copal Electronics CUS-14TB
S9, S10 2
Switches, slide, SP3T
Copal Electronics CUS-13TB
TP1, TP3, TP20 3
Test points
Keystone 5000
U1–U4 4
Dual inverters (6 SC-70)
TI SN74LVC2G14DCKR
U7 1
Low-jitter, frequency synthesizer
with intelligent dynamic switching
(56 TQFN)
Maxim MAX3678UTN+
None 1
PCB: MAX3678 EV Kit+ Circuit
Board, Rev A
PART TYPE
MAX3678EVKIT+ EV Kit
+
Denotes lead-free/RoHS compliant.
E V A L U A T I O N K I T A V A I L A B L E
Microsemi MAX3678UTN+
