MAX31910/11 Evaluation Kit
Evaluates: MAX31910 and MAX31911
19-6443; Rev 0; 9/12
General Description
The MAX31910/11 evaluation kit (EV kit) provides
the hardware and software (graphical user interface)
necessary to evaluate the MAX31910 and MAX31911
industrial octal digital input translators/serializers. The EV
kit includes a MAX31910AUI+ or MAX31911AUI+ installed
as well as a digital isolator and USB-to-SPI interface.
The USB to SPI Dongle is a separate PCB that can be
used to interact with the EV kit software. This dongle is
optional and is not necessary for the proper operation of
the MAX31910/11 if the user supplies the SPI interface.
This EV kit is intended for functional and parametric
evaluation of the IC only; it is not intended for EMC
testing.
EV Kit Contents
S Assembled Circuit Board including
MAX31910AUI+ or MAX31911AUI+
S USB to SPI Dongle
S Mini-USB Cable
Features
S Easy Evaluation of the MAX31910 and MAX31911
S Fully Assembled and Tested
S USB HID Interface
S Digital Isolator
S Windows XP
®
OS- and Windows
®
7
OS-Compatible Software
S RoHS Compliant
MAX31910/11 EV Kit Files
Windows and Windows XP are registered trademarks of Microsoft Corp.
Ordering Information appears at end of data sheet.
MAX31910/11 EV Kit
Note: The .EXE file is downloaded as a .ZIP file.
FILE DESCRIPTION
MAX31910_11EVKitSoftwareInstall.EXE
Application
program
For pricing, delivery, and ordering information, please contact Maxim Direct
at 1-888-629-4642, or visit Maxim’s website at www.maximintegrated.com.
