General Description
The MAX3420E contains the digital logic and analog
circuitry necessary to implement a full-speed USB
peripheral compliant to USB specification rev 2.0. A
built-in full-speed transceiver features ±15kV ESD pro-
tection and programmable USB connect and discon-
nect. An internal serial-interface engine (SIE) handles
low-level USB protocol details such as error checking
and bus retries. The MAX3420E operates using a regis-
ter set accessed by an SPI™ interface that operates up
to 26MHz. Any SPI master (microprocessor, ASIC, DSP,
etc.) can add USB functionality using the simple 3- or
4-wire SPI interface.
Internal level translators allow the SPI interface to run at
a system voltage between 1.71V and 3.6V. USB timed
operations are done inside the MAX3420E with inter-
rupts provided at completion so an SPI master does not
need timers to meet USB timing requirements. The
MAX3420E includes four general-purpose inputs and
outputs so any microprocessor that uses I/O pins to
implement the SPI interface can reclaim the I/O pins
and gain additional ones.
The MAX3420E operates over the extended -40°C to
+85°C temperature range and is available in a 32-pin
LQFP package (7mm x 7mm) and a space-saving 24-
pin TQFN package (4mm x 4mm).
Applications
Features
♦ Microprocessor-Independent USB Solution
♦ Complies with USB Specification Revision 2.0
(Full-Speed Operation)
♦ Integrated Full-Speed USB Transceiver
♦ Firmware/Hardware Control of an Internal D+
Pullup Resistor
♦ Programmable 3- or 4-Wire 26MHz SPI Interface
♦ Level Translators and V
L
Input Allow Independent
System Interface Voltage
♦ Internal Comparator Detects V
BUS
for
Self-Powered Applications
♦ ESD Protection on D+, D-, and VBCOMP
♦ Interrupt Output Pin (Level or Programmable
Edge) Allows Polled or Interrupt-Driven SPI
Interface
♦ Intelligent USB Serial-Interface Engine (SIE)
Automatically Handles USB Flow Control and
Double Buffering
Handles Low-Level USB Signaling Details
Contains Timers for USB Time-Sensitive
Operations So SPI Master Does Not Need to
Time Events
♦ Built-In Endpoint FIFOs
EP0: CONTROL (64 Bytes)
EP1: OUT, Bulk or Interrupt, 2 x 64 Bytes
(Double-Buffered)
EP2: IN, Bulk or Interrupt, 2 x 64 Bytes
(Double-Buffered)
EP3: IN, Bulk or Interrupt (64 Bytes)
♦ Double-Buffered Data Endpoints Increase
Throughput by Allowing the SPI Master to
Transfer Data Concurrently with USB Transfers
Over the Same Endpoint
♦ SETUP Data Has Its Own 8-Byte FIFO, Simplifying
Firmware
♦ Four General-Purpose Inputs and Four General-
Purpose Outputs
♦ Space-Saving LQFP and TQFN Packages
MAX3420E
USB Peripheral Controller
with SPI Interface
________________________________________________________________ Maxim Integrated Products 1
19-3781; Rev 2; 6/07
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
EVALUATION KIT
AVAILABLE
Cell Phones
PC Peripherals
Microprocessors and
DSPs
Custom USB Devices
Cameras
Desktop Routers
PLCs
Set-Top Boxes
PDAs
MP3 Players
Instrumentation
PART
TEMP RANGE
PIN-
PACKAGE
PACKAGE
CODE
M AX 3420E E TG+
- 40°C to + 85°C
24 TQFN - E P *
4m m x 4m m x
0.8m m
T2444- 4
M AX 3420E E C J+
- 40°C to + 85°C
32 LQFP
7m m x 7m m x
1.4m m
C 32- 1
Ordering Information
+Denotes lead-free package.
*EP = Exposed paddle, connected to ground.
SPI is a trademark of Motorola, Inc.
