MAX3674
High-Performance, Dual-Output,
Network Clock Synthesizer
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS
(V
CC
= V
CC_PLL
= +3.3V ±5%, T
A
= -40°C to +85°C, BYPASS = high, TEST_EN = low. Typical values are at V
CC
= V
CC_PLL
= +3.3V,
T
A
= +25°C, unless otherwise noted.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Supply Voltage Range (V
CC
and V
CC_PLL
)...........-0.3V to +3.9V
DC Input Voltage Range (BYPASS, REF_SEL,
REF_CLK, CLK_STOPx, XTAL1, XTAL2,
M[9:0], TEST_EN, NB, NA[2:0], PLOAD,
MR, SDA, SCL, ADR[1:0], P) to GND ......-0.3V to (V
CC
+ 0.3V)
DC Output Voltage Range (LOCK, SDA,
Qx, Qx) ....................................................-0.3V to (V
CC
+ 0.3V)
DC Input Current...............................................................±20mA
DC Output Current ............................................................±50mA
Continuous Power Dissipation (T
A
= +70°C)
48-Pin LQFP (derate 21.7mW/°C above 70°C) ..........1739mW
Operating Ambient Temperature Range (T
A
)......-40°C to +85°C
Operating Junction Temperature (T
J
)..............................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
LVCMOS INPUTS (BYPASS, REF_SEL, REF_CLK, CLK_STOPx, M[9:0], TEST_EN, NB, NA[2:0], PLOAD, MR, ADR[1:0], P)
Input High Voltage V
IH
2.0
V
CC
+
0.3
V
Input Low Voltage V
IL
-0.3 +0.8 V
Input Current I
IH
, I
IL
V
IN
= V
CC
or GND (Note 2) ±200 μA
Input Capacitance C
IN
4.0 pF
I
2
C INPUTS (SDA, SCL)
Input High Voltage V
IH
2.0
V
CC
+
0.3
V
Input Low Voltage V
IL
-0.3 +0.8 V
Input Current I
IH
, I
IL
V
IN
= V
CC
or GND ±10 μA
I
2
C OPEN-DRAIN OUTPUT (SDA)
Output Low Voltage V
OL
I
OL
= +4mA 0.4 V
LVCMOS/TTL OUTPUT (LOCK)
Output High Voltage V
OH
I
OH
= -4mA 2.4 V
Output Low Voltage V
OL
I
OL
= +4mA 0.4 V
LVPECL DIFFERENTIAL CLOCK OUTPUTS (Qx, Qx)
Output High Voltage V
OH
(Note 3)
V
CC
-
1.25
V
CC
-
0.74
V
Output Low Voltage V
OL
(Note 3)
V
CC
-
1.95
V
CC
-
1.45
V
POWER SUPPLY
Supply Voltage V
CC
3.135 3.3 3.465 V
PLL Supply Voltage V
CC_PLL
(Note 4) 3.035 3.3 3.465 V
Includes PECL output currents (Note 3) 120 136
Supply Current I
CC
PECL outputs open 81
mA
PLL Supply Current I
CC_PLL
10 mA
