MAX531 12
10%
1 SO
MAX5156 12
5V ±
10%
2
QSOP
MAX5157 12
2.7V
to
3.6V
2
QSOP
MAX5253 12
3V to
3.6V
4
SSOP
MAX535 13
5V±
10%
1
µMAX
MAX5351 13
3.15V
to
3.6V
1
µMAX
MAX5152 13
5V ±
10%
2
QSOP
MAX5153 13
2.7V
to
3.6V
2
QSOP
*In addition to the packages listed, all parts are available in DIPs.
The 13-bit low-power voltage-output D/A converters shown in Figure 3 include precision output amplifiers
that can drive an external MOSFET directly. You can also bypass this internal amplifier with an external
op amp. SPI™, QSPI™, and Microwire™ compatibility simplifies the converters' data interface, making
them suitable for use with most of the processors and controllers found in industrial-control applications.
Figure 3. This simple, digitally adjustable 4–20mA current loop is suitable for transmission over moderate
distances.
During long-distance signal transmission, the converters' force and sense pins (OUT and FB) compensate
instantly for error voltages at the receiver. These connections to the internal, user-programmable output
amplifier also let you configure a simplified current loop (Figure 4).
Page 4 of 8
