General Description
The MAX6953 is a compact cathode-row display driver
that interfaces microprocessors to 5
✕
7 dot-matrix LED
displays through an I
2
C™-compatible serial interface.
The MAX6953 drives up to four digits (140 LEDs).
Included on-chip are an ASCII 104-character font, mul-
tiplex scan circuitry, column and row drivers, and static
RAM that stores each digit, as well as font data for 24
user-definable characters. The segment current for the
LEDs is set by an internal digit-by-digit digital bright-
ness control.
The device includes a low-power shutdown mode, seg-
ment blinking (synchronized across multiple drivers, if
desired), and a test mode that forces all LEDs on. The
LED drivers are slew-rate limited to reduce EMI.
For an SPI™-compatible version, refer to the MAX6952
data sheet. An EV kit is available for the MAX6952.
Applications
Message Boards
Medical Equipment
Industrial Displays
Audio/Video Equipment
Gaming Machines
Features
♦ 400kbps 2-Wire Interface Compatible with I
2
C
♦ 2.7V to 5.5V Operation
♦ Drives 4 Monocolor or 2 Bicolor Cathode-Row
5
✕
7 Matrix Displays
♦ Built-In ASCII 104-Character Font
♦ 24 User-Definable Characters Available
♦ Automatic Blinking Control for Each Segment
♦ 70µA Low-Power Shutdown (Data Retained)
♦ 16-Step Digital Brightness Control
♦ Display Blanked on Power-Up
♦ Slew-Rate-Limited Segment Drivers for Lower EMI
♦ 36-Pin SSOP and 40-Pin DIP Packages
♦ Extended Temperature Range as Standard
MAX6953
2-Wire Interfaced, 2.7V to 5.5V, 4-Digit 5
✕
7
Matrix LED Display Driver
________________________________________________________________ Maxim Integrated Products 1
Ordering Information
DIGIT 1
R1
R6
R7
C1
R4
R3
R2
R5
C2
C3
C5
C4
