MC68HC908QY4A Data Sheet, Addendum 5/2012
Freescale Semiconductor 1
Addendum to MC68HC908QY4A, rev. 3
This addendum introduces a change to this data sheet.
Chapter 15 Development Support, Section 15.3.2 Security
A security feature discourages unauthorized reading of FLASH locations while in monitor mode. The host
can bypass the security feature at monitor mode entry by sending eight security bytes that match the
bytes at locations $FFF6–$FFFD. Locations $FFF6–$FFFD contain user-defined data.
NOTE
Do not leave locations $FFF6–$FFFD blank. For security reasons, program
locations $FFF6–$FFFD even if they are not used for vectors.
Changes to:
Chapter 15 Development Support, Section 15.3.2 Security
A security feature discourages unauthorized reading of FLASH locations while in monitor mode. The host
can bypass the security feature at monitor mode entry by sending eight security bytes that match the
bytes at locations $FFF6–$FFFD. Locations $FFF6–$FFFD contain user-defined data.
NOTE
Do not leave locations $FFF6–$FFFD blank. For security reasons, program
locations $FFF6–$FFFD even if they are not used for vectors. An improved
security function denies monitor mode entry if five or more of the eight
security bytes are $00 (zero bytes).
