© Semiconductor Components Industries, LLC, 2005
June, 2005 − Rev. 9
1 Publication Order Number:
MC74HC4538A/D
MC74HC4538A
Dual Precision Monostable
Multivibrator (Retriggerable,
Resettable)
The MC74HC4538A is identical in pinout to the MC14538B. The
device inputs are compatible with standard CMOS outputs; with
pullup resistors, they are compatible with LSTTL outputs.
This dual monostable multivibrator may be triggered by either the
positive or the negative edge of an input pulse, and produces a
precision output pulse over a wide range of pulse widths. Because the
device has conditioned trigger inputs, there are no trigger−input rise
and fall time restrictions. The output pulse width is determined by the
external timing components, R
x
and C
x
. The device has a reset
function which forces the Q output low and the Q output high,
regardless of the state of the output pulse circuitry.
