© Semiconductor Components Industries, LLC, 2007
February, 2007 − Rev. 11
1 Publication Order Number:
MC74HC1G08/D
MC74HC1G08
Single 2−Input AND Gate
The MC74HC1G08 is a high speed CMOS 2−input AND gate
fabricated with silicon gate CMOS technology.
The internal circuit is composed of multiple stages, including a
buffer output which provides high noise immunity and stable output.
The MC74HC1G08 output drive current is 1/2 compared to
MC74HC series.
Features
• High Speed: t
PD
= 7 ns (Typ) at V
CC
= 5 V
• Low Power Dissipation: I
CC
= 1 mA (Max) at T
A
= 25°C
• High Noise Immunity
• Balanced Propagation Delays (t
pLH
= t
pHL
)
• Symmetrical Output Impedance (I
OH
= I
OL
= 2 mA)
• Chip Complexity: FET = 44
• Pb−Free Packages are Available
Figure 1. Pinout
Figure 2. Logic Symbol
IN A
IN B
OUT Y
&
V
CC
IN B
IN A
OUT YGND
1
2
34
5
L
L
H
H
L
H
L
H
FUNCTION TABLE
Inputs Output
AB
L
L
L
H
Y
See detailed ordering and shipping information in the
package dimensions section on page 4 of this data sheet.
ORDERING INFORMATION
PIN ASSIGNMENT
1
2
3 GND
IN B
IN A
4
5V
CC
OUT Y
http://onsemi.com
MARKING
DIAGRAMS
H2 = Device Code
M = Date Code*
G = Pb−Free Package
SC−88A / SOT−353 / SC−70
DF SUFFIX
CASE 419A
TSOP−5 / SOT−23 / SC−59
DT SUFFIX
CASE 483
H2 M G
G
1
5
H2 M G
G
M
1
5
(Note: Microdot may be in either location)
*Date Code orientation and/or position may vary
depending upon manufacturing location.
