© Semiconductor Components Industries, LLC, 2012
June, 2021 − Rev. 17
1 Publication Order Number:
MC74HC1G08/D
Single 2-Input AND Gate
MC74HC1G08
The MC74HC1G08 is a high speed CMOS 2−input AND gate
fabricated with silicon gate CMOS technology.
The internal circuit is composed of multiple stages, including a
buffer output which provides high noise immunity and stable output.
The MC74HC1G08 output drive current is 1/2 compared to
MC74HC series.
Features
• High Speed: t
PD
= 7 ns (Typ) at V
CC
= 5 V
• Low Power Dissipation: I
CC
= 1 mA (Max) at T
A
= 25°C
• High Noise Immunity
• Balanced Propagation Delays (t
pLH
= t
pHL
)
• Symmetrical Output Impedance (I
OH
= I
OL
= 2 mA)
• Chip Complexity: < 100 FETs
• NLV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements; AEC−Q100
Qualified and PPAP Capable
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
Figure 1. Pinout
Figure 2. Logic Symbol
A
B
Y
&
V
CC
B
A
YGND
1
2
34
5
PIN ASSIGNMENT
1
2
3 GND
B
A
4
5V
CC
Y
L
L
H
H
L
H
L
H
FUNCTION TABLE
Inputs Output
AB
L
L
L
H
Y
See detailed ordering, marking and shipping information in
the package dimensions section on page 6 of this data
ORDERING INFORMATION
www.onsemi.com
MARKING
DIAGRAMS
XX = Device Code
M = Date Code*
A = Assembly Location
Y = Year
W = Work Week
G = Pb−Free Package
SC−88A
DF SUFFIX
CASE 419A
TSOP−5
DT SUFFIX
CASE 483
XX MG
G
1
5
XX MG
G
M
1
5
(Note: Microdot may be in either location)
*Date Code orientation and/or position may vary
depending upon manufacturing location.
1
5
XXX MG
G
SC−74A
DBV SUFFIX
CASE 318BQ
XXX = Specific Device Code
M = Date Code
G = Pb−Free Package
(Note: Microdot may be in either location)
1
5
XXXAYWG
G
