MC78XXE — 3-Terminal 1A Positive Voltage Regulator
© 2003 Fairchild Semiconductor Corporation www.fairchildsemi.com
MC78XXE Rev. 1.6
April 2015
MC78XXE
3-Terminal 1A Positive Voltage Regulator
Features
• Output Current up to 1 A
• Output Voltages of 5 V, 12 V
• Thermal Overload Protection
• Short-Circuit Protection
• Output Transistor Safe Operating Area Protection
Ordering Information
Product Number Marking Package Packing Method
Output Voltage
Tolerance
Operating
Temperature
MC7805ECDTX MC7805 TO-252 3L (D-PAK) Tape and Reel
±4% -40 to +125°C
MC7812ECDTX MC7812 TO-252 3L (D-PAK) Tape and Reel
Description
The MC78XXE series of three terminal positive regula-
tors are available in the D-PAK package and with several
fixed output voltages, making them useful in a wide range
of applications. Each type employs internal current limit-
ing, thermal shut down and safe operating area protec-
tion, making it essentially indestructible. If adequate heat
sinking is provided, they can deliver over 1 A output cur-
rent. Although designed primarily as fixed voltage regula-
tors, these devices can be used with external
components to obtain adjustable voltages and currents.
D-PAK
1. Input 2. GND 3. Output
1
GND
