© Freescale Semiconductor, Inc., 2005, 2006. All rights reserved.
Freescale Semiconductor
Product Brief
MC9S12CFAMPB
Rev. 5, 03/2006
MC9S12C-Family
16-Bit Microcontroller
Based on Freescale’s market-leading flash technology, members of the MC9S12C-Family deliver the
power and flexibility of our 16 Bit core (CPU12) family to a whole new range of cost and space sensitive,
general purpose Industrial and Automotive network applications. MC9S12C-Family members are
comprised of standard on-chip peripherals including a 16-bit central processing unit (CPU12), up to 128K
bytes of Flash EEPROM or ROM, up to 4K bytes of RAM, an asynchronous serial communications
interface (SCI), a serial peripheral interface (SPI), an 8-channel 16-bit timer module (TIM), a 6-channel
8-bit pulse width modulator (PWM), an 8-channel, 10-bit analog-to-digital converter (ADC) and up to one
CAN 2.0 A, B software compatible module (MSCAN12). The MC9S12C-Family has full 16-bit data paths
throughout. The inclusion of a PLL circuit allows power consumption and performance to be adjusted to
suit operational requirements. In addition to the I/O ports available in each module, up to 10 dedicated I/O
port bits are available with Wakeup capability from STOP or WAIT mode. The MC9S12C-Family is
available in 48-pin and 52-pin LQFP, and in 80-pin QFP packages (all RoHS Compliant J-STD-020C); the
80-pin version is pin-compatible with the HCS12B- and D-Family derivatives.
The C-Family includes ROM versions MC3S12C128/96/64/32/16 of all devices which provide a further
cost reduction path for applications with high volume and stable code.
1Features
• 16-Bit HCS12 CORE
— HCS12 CPU
— MMC (memory map and interface)
— INT (interrupt control)
— BDM (background debug mode)
— DBG12 (enhanced debug12 module including breakpoints and change-of-flow trace buffer)
— Multiplexed Expansion Bus (available only in 80-pin package version)
