Introduction
i.MX28 Applications Processors for Consumer Products, Rev. 3
Freescale Semiconductor 3
• One debug UART operating at up to 115 Kb/s using programmed I/O
•Two I
2
C master/slave interfaces, up to 400 kbps
• Four 32-bit timers and a rotary decoder
• Eight Pulse Width Modulators (PWMs)
• Real-time clock (RTC)
• GPIO with interrupt capability
• Power Management Unit (PMU) supports a triple output DC-DC switching converter, multiple
linear regulators, battery charger, and detector.
• 16-channel Low-Resolution A/D Converter (LRADC). There are 16 physical channels but they can
only be mapped to 8 virtual channels at a time.
• Single channel High Speed A/D Converter (HSADC), up to 2 Msps data rate
• 4/5-wire touchscreen controller
• Up to 8X8 keypad matrix with button-detect circuit
• Security features:
— Read-only unique ID for Digital Rights Management (DRM) algorithms
— Secure boot using 128-bit AES hardware decryption
— SHA-1 and SHA256 hashing hardware
— High assurance boot (HAB4)
• Offered in 289-pin Ball Grid Array (BGA)
1.2 Ordering Information and Functional Part Differences
Table 1 provides the ordering information for the i.MX28.
Table 1. Ordering Information
Part Number Projected Temperature Range (°C) Package
MCIMX280DVM4B –20 to +70 14 x 14 mm, 0.8mm pitch, MAPBGA-289
MCIMX280CVM4B –40 to +85 14 x 14 mm, 0.8mm pitch, MAPBGA-289
MCIMX283DVM4B –20 to +70 14 x 14 mm, 0.8 mm pitch, MAPBGA-289
MCIMX283CVM4B –40 to +85 14 x 14 mm, 0.8 mm pitch, MAPBGA-289
MCIMX286DVM4B –20 to +70 14 x 14 mm, 0.8 mm pitch, MAPBGA-289
MCIMX286CVM4B –40 to +85 14 x 14 mm, 0.8 mm pitch, MAPBGA-289
MCIMX287CVM4B –40 to +85 14 x 14 mm, 0.8 mm pitch, MAPBGA-289
