MCP3901 双路 ADC 评估板此评估板用于 16 位 MCU 系统，可评估 MCP3901 24 位双通道 ADC 的性能。 它还提供用于基于 16 位 PIC 应用的开发平台，使用现有 100 引脚 PIM 模块。编程的 dsPIC33FJ256GP710 PIM 模块，可与 LabView GUI 进行通信，用于数据数据交换和 ADC 设置 使用串行至 PC 的连接进行双路 24 位 ADC MCP3901 输出显示 USB 连接，用于更高的速度采样和数据收集 90dB SINAD 时同步 4ksps 且双通道上最高速度 55ksps 性能 通过图形 PC 工具进行系统和 ADC 性能分析，显示噪声矩形图、频率域 (FFT)、时间域示波器图表和统计数字分析 坚固的硬件设计，带模拟接地和模拟/数字分离，用于噪声性能评估 单独的电源和电源层：4 层印刷电路板 PICtail™ Plus 连接器，用于 Explorer-16 子板兼容性 ### 注需要 RS-232 电缆或 USB 到 RS-232 适配器电缆。### 模数转换器 - Microchip
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
应用领域在P2P8P31
导航目录
MCP3901EV-MCU16数据手册
Page:
of 36 Go
若手册格式错乱，请下载阅览PDF原文件
www.microchip.com/tools
6
Software Tools
Atmel START
Atmel START is an innovative online tool for intuitive, graphical conguration of
embedded software projects. It lets you select and congure software components,
drivers and middleware, as well as complete example projects, specically tailored to
the needs of your application. The conguration stage lets you review dependencies between software components, conicts and
hardware constraints. In the case of a conict, Atmel START will automatically suggest solutions that t your specic setup.
With graphical pin-mux and clock conguration, you can easily match your software and drivers with your own hardware layout.
The tool also provides automated assistance for retargeting projects and applications for dierent devices. Getting that sample
code to run on your board has never been easier.
Since Atmel START is an online tool, no installation is required. When you are nished with your conguration, you can download
it for use together with your preferred Integrated Development Environment (IDE), including Atmel Studio, Keil or IAR and continue
development. If you later need to change the conguration you can load it in Atmel START, recongure and continue where you
left o.
Atmel START is based on the latest generation of the Atmel Software Framework, ASFv4. The driver layer in ASFv4 has been
rearchitected for better performance and reduced code size. Care has been taken to make sure that code generated by Atmel
START is readable, as well as easy to navigate and extend. Please refer to the user guide to learn more about what’s new in
ASFv4.
You can download and securely purchase both Microchip and third-party compilers, advanced debugging tools, real-time
operating systems, communication systems and other extensions and plug-ins straight from the Atmel Studio 7 development
platform.
MPLAB
®
Mindi
TM
Analog Simulator
MPLAB Mindi Analog Simulator reduces circuit design time and design risk by simulating
analog circuits prior to hardware prototyping. The simulation tool uses a SIMetrix/SIMPLIS
simulation environment, with options to use SPICE or piecewise linear modeling, that can
cover a very wide set of possible simulation needs. This capable simulation interface is paired
with proprietary model les from Microchip, to model specic Microchip analog components
in addition to generic circuit devices. Finally, this simulation tool installs and runs locally, on the
your own PC. Once downloaded, no internet connection is required, and the simulation run
time is not dependent on a remotely located server. The result is fast, accurate analog circuit
simulations. Benets include:
• Run the simulation tool directly on your own PC; once installed no internet connection is
required
• Choose from SPICE or piecewise linear SIMPLIS models, for accurate results in fast simulations
• Model a wide variety of analog systems using standard or Microchip proprietary component models
• Generate time or frequency domain responses for open and closed loop systems
• Perform AC, DC and transient analysis
• Use sweep modes to identify circuit sensitivities to device behaviors, load variations, or tolerances
• Validate system response, control and stability
• Identify problems before building hardware
