© 2005 Microchip Technology Inc. DS21733F-page 1
MCP6001/2/4
Features
• Available in SC-70-5 and SOT-23-5 packages
• Gain Bandwidth Product: 1 MHz (typ.)
• Rail-to-Rail Input/Output
• Supply Voltage: 1.8V to 5.5V
• Supply Current: I
Q
= 100 µA (typ.)
• Phase Margin: 90° (typ.)
• Temperature Range:
- Industrial: -40°C to +85°C
- Extended: -40°C to +125°C
• Available in Single, Dual and Quad Packages
Applications
• Automotive
• Portable Equipment
• Photodiode Amplifier
• Analog Filters
• Notebooks and PDAs
• Battery-Powered Systems
Available Tools
SPICE Macro Models (at www.microchip.com)
FilterLab
®
Software (at www.microchip.com)
Typical Application
Description
The Microchip Technology Inc. MCP6001/2/4 family of
operational amplifiers (op amps) is specifically
designed for general-purpose applications. This family
has a 1 MHz Gain Bandwidth Product (GBWP) and
90° phase margin (typ.). It also maintains 45° phase
margin (typ.) with a 500 pF capacitive load. This family
operates from a single supply voltage as low as 1.8V,
while drawing 100 µA (typ.) quiescent current.
Additionally, the MCP6001/2/4 supports rail-to-rail
input and output swing, with a common mode input
voltage range of V
DD
+300mV to V
SS
– 300 mV. This
family of op amps is designed with Microchip’s
advanced CMOS process.
The MCP6001/2/4 family is available in the industrial
and extended temperature ranges, with a power supply
range of 1.8V to 5.5V.
Package Types
R
1
V
OUT
R
2
V
IN
V
DD
+
–
Gain 1
R
1
R
2
------
+=
Non-Inverting Amplifier
MCP6001
V
REF
V
SS
4
5
4
5
4
MCP6001
1
2
3
-
+
5
V
DD
V
IN
–
V
OUT
V
SS
V
IN
+
SC-70-5, SOT-23-5
MCP6002
PDIP, SOIC, MSOP
MCP6004
V
INA
+
V
INA
–
V
SS
1
2
3
4
14
13
12
11
-
V
OUTA
+
-
+
V
DD
V
OUTD
V
IND
–
V
IND
+
10
9
8
5
6
7
V
OUTB
V
INB
–
V
INB
+V
INC
+
V
INC
–
V
OUTC
+
-
-
+
PDIP, SOIC, TSSOP
V
INA
+
V
INA
–
V
SS
1
2
3
4
8
7
6
5
-
V
OUTA
+
-
+
V
DD
V
OUTB
V
INB
–
V
INB
+
4
1
2
3
-
+
5
V
DD
V
OUT
V
SS
MCP6001R
SOT-23-5
1
2
3
-
+
V
SS
V
IN
–
V
OUT
V
DD
V
IN
+
MCP6001U
SOT-23-5
1
2
3
-
+
V
DD
V
OUT
V
IN
+
V
SS
V
IN
–
1 MHz, Low-Power Op Amp
