© 2009 Microchip Technology Inc. DS21733J-page 1
MCP6001/1R/1U/2/4
Features
• Available in SC-70-5 and SOT-23-5 packages
• Gain Bandwidth Product: 1 MHz (typical)
• Rail-to-Rail Input/Output
• Supply Voltage: 1.8V to 6.0V
• Supply Current: I
Q
= 100 µA (typical)
• Phase Margin: 90° (typical)
• Temperature Range:
- Industrial: -40°C to +85°C
- Extended: -40°C to +125°C
• Available in Single, Dual and Quad Packages
Applications
• Automotive
• Portable Equipment
• Photodiode Amplifier
• Analog Filters
• Notebooks and PDAs
• Battery-Powered Systems
Design Aids
• SPICE Macro Models
• FilterLab
®
Software
• Mindi™ Circuit Designer & Simulator
• Microchip Advanced Part Selector (MAPS)
• Analog Demonstration and Evaluation Boards
• Application Notes
Typical Application
Description
The Microchip Technology Inc. MCP6001/2/4 family of
operational amplifiers (op amps) is specifically
designed for general-purpose applications. This family
has a 1 MHz Gain Bandwidth Product (GBWP) and 90°
phase margin (typical). It also maintains 45° phase
margin (typical) with a 500 pF capacitive load. This
family operates from a single supply voltage as low as
1.8V, while drawing 100 µA (typical) quiescent current.
Additionally, the MCP6001/2/4 supports rail-to-rail input
and output swing, with a common mode input voltage
range of V
DD
+ 300 mV to V
SS
– 300 mV. This family of
op amps is designed with Microchip’s advanced CMOS
process.
The MCP6001/2/4 family is available in the industrial
and extended temperature ranges, with a power supply
range of 1.8V to 6.0V.
Package Types
R
1
V
OUT
R
2
V
IN
V
DD
+
–
Gain 1
R
1
R
2
------+=
Non-Inverting Amplifier
MCP6001
V
REF
V
SS
4
5
4
5
4
MCP6001
1
2
3
-
+
5
V
DD
V
IN
–
V
OUT
V
SS
V
IN
+
SC70-5, SOT-23-5
MCP6002
PDIP, SOIC, MSOP
MCP6004
V
INA
+
V
INA
–
V
SS
1
2
3
4
14
13
12
11
-
V
OUTA
+
-
+
V
DD
V
OUTD
V
IND
–
V
IND
+
10
9
8
5
6
7
V
OUTB
V
INB
–
V
INB
+V
INC
+
V
INC
–
V
OUTC
+
-
-
+
PDIP, SOIC, TSSOP
V
INA
+
V
INA
–
V
SS
1
2
3
4
8
7
6
5
-
V
OUTA
+
-
+
V
DD
V
OUTB
V
INB
–
V
INB
+
4
1
2
3
-
+
5
V
DD
V
OUT
V
SS
MCP6001R
SOT-23-5
1
2
3
-
+
V
SS
V
IN
–
V
OUT
V
DD
V
IN
+
MCP6001U
SOT-23-5
1
2
3
-
+
V
DD
V
OUT
V
IN
+
V
SS
V
IN
–
MCP6002
V
INA
+
V
INA
–
V
SS
V
OUTB
V
INB
–
1
2
3
4
8
7
6
5
V
INB
+
V
OUTA
EP
9
V
DD
2x3 DFN *
* Includes Exposed Thermal Pad (EP); see Table 3-1.
1 MHz, Low-Power Op Amp
