2004 Microchip Technology Inc. DS21882B-page 1
MCP6241/2
Features
• Gain Bandwidth Product: 650 kHz (typ.)
• Supply Current: I
Q
= 50 µA (typ.)
• Supply Voltage: 1.8V to 5.5V
• Rail-to-Rail Input/Output
• Extended Temperature Range: -40°C to +125°C
• Available in 5-pin SC-70 and SOT-23 packages
Applications
• Automotive
• Portable Equipment
• Photodiode (Transimpedance) Amplifier
• Analog Filters
• Notebooks and PDAs
• Battery-Powered Systems
Available Tools
SPICE Macro Models (at www.microchip.com)
FilterLab
®
Software (at www.microchip.com)
Typical Application
Description
The Microchip Technology Inc. MCP6241/2 operational
amplifiers (op amps) provide wide bandwidth for the
quiescent current. The MCP6241/2 has a 650 kHz Gain
Bandwidth Product (GBWP) and 77° (typ.) phase
margin. This family operates from a single supply
voltage as low as 1.8V, while drawing 50 µA (typ.)
quiescent current. In addition, the MCP6241/2 family
supports rail-to-rail input and output swing, with a
common mode input voltage range of V
DD
+300mV to
V
SS
– 300 mV. These op amps are designed in one of
Microchip’s advanced CMOS processes.
Package Types
MCP6241
V
OUT
V
IN2
–
+
V
IN1
R
G2
R
G1
R
F
R
Z
V
DD
R
X
R
Y
Summing Amplifier Circuit
4
MCP6241
1
2
3
–
+
5
V
DD
V
IN
–
V
OUT
V
SS
V
IN
+
SOT-23-5
1
+
5
V
DD
V
OUT
V
SS
MCP6241R
SOT-23-5
4
1
2
3
–
+
5
V
SS
V
IN
–
V
OUT
V
DD
V
IN
+
MCP6241U
SC-70-5, SOT-23-5
4
1
2
3
–
+
5
V
DD
V
OUT
V
IN
+
V
SS
V
IN
–
V
IN
+
V
IN
–
MCP6241
V
SS
V
DD
V
OUT
1
2
3
4
8
7
6
5
–
+
NC
NC
NC
PDIP, SOIC, MSOP
MCP6242
PDIP, SOIC, MSOP
1
2
3
4
8
7
6
5
-
+
-
+
A
B
V
INA
_
V
INA
+
V
SS
V
OUTA
V
OUTB
V
DD
V
INB
_
V
INB
+
50 µA, 650 kHz Rail-to-Rail Op Amp
