2003-2020 Microchip Technology Inc. DS20001812G-page 1
MCP6291/1R/2/3/4/5
Features
• Gain Bandwidth Product: 10 MHz (typical)
• Supply Current: I
Q
= 1.0 mA
• Supply Voltage: 2.4V to 6.0V
• Rail-to-Rail Input/Output
• Extended Temperature Range: -40°C to +125°C
• Available in Single, Dual and Quad Packages
• High Temperature Range:
-40°C to +150°C
• Single with CS
(MCP6293)
• Dual with CS
(MCP6295)
Applications
• Automotive (see Product Identification System
(Automotive))
- AEC-Q100 Qualified. Grade 1.
- AEC-Q100 Qualified, Grade 0 (MCP6292
H-Temp)
• Portable Equipment
• Photodiode Amplifier
• Analog Filters
• Notebooks and PDAs
• Battery-Powered Systems
Design Aids
• SPICE Macro Models
•FilterLab
®
Software
• Mindi™ Simulation Tool
• MAPS (Microchip Advanced Part Selector)
• Analog Demonstration and Evaluation Boards
• Application Notes
Description
The Microchip Technology Inc. MCP6291/1R/2/3/4/5
family of operational amplifiers (op amps) provide wide
bandwidth for the current. This family has a 10 MHz
Gain Bandwidth Product (GBWP) and a 65° phase
margin. This family also operates from a single supply
voltage as low as 2.4V, while drawing 1 mA (typical)
quiescent current. In addition, the MCP6291/1R/2/3/4/5
supports rail-to-rail input and output swing, with a
Common-mode input voltage range of V
DD
+ 300 mV to
V
SS
– 300 mV. This family of operational amplifiers is
designed with Microchip’s advanced CMOS process.
The MCP6295 has a Chip Select (CS
) input for dual op
amps in an 8-pin package. This device is manufactured
by cascading the two op amps, with the output of
op amp A being connected to the noninverting input of
op amp B. The CS input puts the device in a Low-power
mode.
The MCP6291/1R/2/3/4/5 family operates over the
extended temperature range of -40°C to +125°C. The
MCP6292 H-Temp part is available in the 8-Lead
MSOP package and operates over the high
temperature range of -40°C to +150°C. It also has a
power supply range of 2.4V to 6.0V.
Package Types
1
2
3
4
V
IN
_
MCP6291
V
DD
1
2
3
4
8
7
6
5
-
+
NC
NC
NC
V
IN
+
V
SS
MCP6292
PDIP, SOIC, MSOP
MCP6294
1
2
3
4
14
13
12
11
-
+
-
+
10
9
8
5
6
7
+
-
-
+
PDIP, SOIC, TSSOP
1
2
3
4
8
7
6
5
-
+
-
+
V
OUT
MCP6293
8
7
6
5
-
+
V
INA
_
V
INA
+
V
SS
V
OUTA
V
OUTB
V
DD
V
INB
_
V
INB
+
V
SS
V
IN
+
V
IN
_
NC
CS
V
DD
V
OUT
NC
V
OUTA
V
INA
_
V
INA
+
V
DD
V
SS
V
OUTB
V
INB
_
V
INB
+
V
OUTC
V
INC
_
V
INC
+
V
OUTD
V
IND
_
V
IND
+
PDIP, SOIC, MSOP
PDIP, SOIC, MSOP
MCP6295
PDIP, SOIC, MSOP
1
2
3
4
8
7
6
5
+
-
V
INA
_
V
INA
+
V
SS
V
OUTA
/V
INB
+
V
OUTB
V
DD
V
INB
_
CS
-
+
MCP6291
SOT-23-5
4
1
2
3
-
+
5
V
DD
V
IN
–
V
OUT
V
SS
V
IN
+
MCP6291R
SOT-23-5
4
1
2
3
-
+
5
V
SS
V
IN
–
V
OUT
V
DD
V
IN
+
MCP6293
SOT-23-6
4
1
2
3
-
+
6
5
V
SS
V
IN
+
V
OUT
CS
V
DD
V
IN
–
1.0 mA, 10 MHz Rail-to-Rail Op Amp
