Freescale Semiconductor
Product Brief
Document Number: MPC8313EPB
Rev. 0, 12/2006
Contents
© Freescale Semiconductor, Inc., 2006. All rights reserved.
This document provides an overview of the MPC8313E
PowerQUICC™ II Pro processor features, including a
block diagram showing the major functional
components. The MPC8313E is a cost-effective,
low-power, highly integrated host processor that
addresses the requirements of several printing and
imaging, consumer, and industrial applications,
including main CPUs and I/O processors in printing
systems, networking switches and line cards, wireless
LANs (WLANs), network access servers (NAS), VPN
routers, intelligent NIC, and industrial controllers. The
MPC8313E extends the PowerQUICC™ family, adding
higher CPU performance, additional functionality, and
faster interfaces while addressing the requirements
related to time-to-market, price, power consumption, and
package size. This document also supports the MPC8313
host processors but is written from the perspective of the
MPC8313E.
1 Application Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.1 Low-End Printer CPU and Interface ASIC. . . . . . . . 2
1.2 High-End Printer I/O Processor . . . . . . . . . . . . . . . . 2
1.3 IEEE Std. 1588 in Test and Measurement and Indus-
trial Automation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 802.11n WLAN Access Point . . . . . . . . . . . . . . . . . 5
1.4.1 Media Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 Critical Performance Parameters . . . . . . . . . . . . . . 7
2.3 Chip-Level Features. . . . . . . . . . . . . . . . . . . 8
2.4 Module Features . . . . . . . . . . . . . . . . . . . . . 8
2.4.1 Security Engine . . . . . . . . . . . . . . . . . . . . . . 8
2.4.2 DDR Memory Controller. . . . . . . . . . . . . . . . 9
2.4.3 PCI Controller. . . . . . . . . . . . . . . . . . . . . . . . 9
2.4.4 USB Dual-Role Controller . . . . . . . . . . . . . . 9
2.4.5 Dual Enhanced Three-Speed Ethernet
Controllers (eTSECs) . . . . . . . . . . . . . . . . . 10
2.4.6 Programmable Interrupt Controller (PIC) . . 10
2.4.7 Power Management Controller (PMC) . . . . 10
2.4.8 Serial Peripheral Interface (SPI) . . . . . . . . 10
2.4.9 DMA Controller, Dual I
2
C, DUART, Enhanced
Local Bus Controller, and Timers. . . . . . . . 11
3 Development Environment . . . . . . . . . . . . . . . . . . . . . . . 11
4 Document Revision History. . . . . . . . . . . . . . . . . . . . . . . 12
MPC8313E PowerQUICC™ II Pro
Processor Product Brief
