MS27484T22F55P数据手册
Page:
of 50 Go
若手册格式错乱，请下载阅览PDF原文件
65
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
II
Dualok
III
SJT
38999
I
HD
Fiber
Optics
Contacts
Connectors
Cables
HIGH
SPEED
26482
Matrix 2
83723 III
Matrix|Pyle
5015
Crimp Rear
Release
Matrix
26500
Pyle
22992
Class L
Back-
Shells
Options
Others
EMI Filter
Transient
PCB
Accessories
Aquacon
Herm/Seal
Amphenol
Aerospace
MIL-DTL-38999
MS27472
Crimp Wall Mount Receptacle
MS27497
Crimp Wall Mount Receptacle (Back Panel
Mounting)
MS27499
Crimp Box Mounting Receptacle
MS27513
Crimp Box Mounting Receptacle with grommet
MS27508
Crimp Box Mounting Receptacle (Back Panel
Mounting)
MS27473
Crimp Straight Plug
MS27484
Crimp Straight Plug with Grounding Fingers
MS27474
Crimp Jam Nut Receptacle
MS27500
Crimp 90° plug
MS27475
Hermetic Wall Mounting Receptacle
MS27476
Hermetic Box Mounting Receptacle
MS27477
Hermetic Jam Nut Receptacle
MS27478
Hermetic Solder Mounting Receptacle
MIL-DTL-27599
MS27334
Solder Wall Mount Receptacle
MS27335
Solder Box Mounting Receptacle
MS27336
Solder Straight Plug
MS27337
Solder Jam Mounting Receptacle
MIL-DTL-38999
MS27466
Crimp Wall Mount Receptacle
MS27656
Crimp Wall Mount Receptacle (Back Panel
Mounting)
MS27496
Crimp Box Mounting Receptacle
MS27505
Crimp Box Mounting Receptacle (Back Panel
Mounting)
MS27467
Crimp Straight Plug
MS27468
Crimp Jam Nut Receptacle
MS27469
Hermetic Wall Mounting Receptacle
MS27470
Hermetic Jam Nut Receptacle
MS27471
Hermetic Solder Mounting Receptacle
MIL-DTL-27599
MS20026
Solder Wall Mounting Receptacle
MS20027
Solder Line Receptacle
MS20028
Solder Straight Plug
MS20029
Solder Jam Nut Receptacle
MS Number Service Class Shell Size Finish Insert
Arrangement
Contact Style
(P or S)
Alternate Keying
Position
MS27473 E 14 A 18 P A
Easy Steps to build a Military part number... Series I and II
1. 2. 3. 4. 5. 6. 7.
Step 1. Choose your Military Connector Type
Military
1. 2. 3. 4. 5. 6. 7.
MS Number
Service Class Shell Size Finish Insert
Arrangement
Contact Style
(P or S)
Alternate
Position
MS27473
Series II JT Series I LJT
Step 2. Select a Military Service Class
Military Service Class
E
Environmental crimp applications. Supplied with a grommet and compression nut.† Can be supplied with strain relief integral
with compression nut “RE(SR)”. (JT Series only). Box Mount versions using spacer grommets are not environmental.
P
Potting crimp applications. Supplied with spacer grommet and potting boot.††
T
Environmental applications. Supplied without rear accessories. Design provides serrations on rear threads of shells.
(Not applicable to solder type or hermetics)
Y
Hermetically interfacial seal
1. 2. 3. 4. 5. 6. 7.
MS Number
Service
Class
Shell Size Finish Insert
Arrangement
Contact Style
(P or S)
Alternate
Position
E
MIL-DTL-38999/ 27599, Series II JT
MIL-DTL-38999/ 27599, Series I LJT
How to Order (Military)
† Not applicable to box mounting style or LJT Series I.
†† Not applicable to box mounting style.
